John Boos UBS4-2148-X Bar Equipment
Description
John Boos UBS4-2148 Underbar 4-Compartment Sink – 48" x 21"
Heavy-duty 18 GA Type 300 stainless steel, NSF ListedDesigned for the rigors of high-volume bars, tasting rooms, and beverage stations, the John Boos UBS4-2148 delivers four generous wash wells in a compact 48-inch footprint. Its all-stainless construction, removable faucet plates, and adjustable bullet feet make installation simple while ensuring years of corrosion-resistant performance.
Why you’ll love it
- Four 10" W x 14" F-B x 10" D bowls handle washing, rinsing, sanitizing & dumping tasks simultaneously.
- 18-gauge, Type 300 stainless steel with #4 satin finish resists dents, chemicals, and everyday abuse.
- 3" integrated backsplash with two removable faucet plates pre-punched on 4" centers for splash-mount mixing faucets (sold separately).
- Includes four 1-1/2" drains with basket strainers and overflow stand pipes (PB-OVF-BS) to keep service moving.
- Bolt-on 1-5/8" stainless legs, front-to-back side bracing, and 1" adjustable stainless bullet feet for fast leveling on uneven floors.
- Pre-drilled side holes let you gang multiple underbar units together for a seamless, custom line-up.
- NSF Listed for regulated food-service environments.
Technical specs
| Model | UBS4-2148 |
|---|---|
| Overall dimensions (W × D × H) | 48" × 21" × 32-1/2" |
| Number of compartments | 4 |
| Compartment size (each) | 10" W × 14" front-to-back × 10" D |
| Backsplash height | 3" |
| Faucet mounting | (2) removable plates with 4" O.C. splash-mount holes |
| Drain size / type | 1-1/2" NPS with basket strainers & overflow stand pipes |
| Material & finish | 18 GA Type 300 stainless steel, #4 satin polish |
| Legs & bracing | Stainless steel legs, side bracing, 1" adjustable bullet feet |
| Unit weight | 80 lb (shipping weight may vary with packaging) |
| Certifications | NSF |
Installation & assembly
- Bolt-on legs ship loose for quicker transport and on-site assembly.
- Z-clip provided for optional wall mounting and additional stability.
- Side holes accept #8-32 hardware (included) for ganging with other John Boos underbar equipment.
Popular accessories (sold separately)
- PBF-4SM2-10LF Heavy-Duty 4" splash-mount faucet
- PBF-W2-10LF Economy 4" splash-mount faucet
- UBSS-21-L / UBSS-21-R Stainless steel side splashes
- PB-WL-36 Flexible shallow-mount faucet hoses
Faucets and side splashes are shown for reference only and are not included unless specifically added to your order.
