John Boos  |  Slim-Line  |  SKU: UBS4-1896-2D24-X

John Boos UBS4-1896-2D24-X Slim-Line Bar Equipment

$2,564.10
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Assembly instructions Instructions Care & maintenance
Related Searches
Bar Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

John Boos Slim-Line 4-Compartment Underbar Sink – 96"W

Model UBS4-1896-2D24 | 18" Deep | Dual 24" Drainboards

Maximize throughput behind the bar without giving up valuable aisle space. The John Boos Slim-Line 4-Compartment Underbar Sink packs full-service washing, rinsing, and sanitizing capacity into a slim 18" footprint—engineered for the fast-paced demands of today’s bars, taprooms, and tasting rooms.

Key Features

  • Four fabricated bowls – 10"W × 14"F/B × 10"D – ideal for full 3-stage warewashing plus dump station.
  • (2) 24" integral drainboards (left & right) with removable perforated inserts for rapid air-drying.
  • Slim 18" front-to-back design keeps traffic lanes clear.
  • 3" backsplash with removable faucet plates; 4" on-center splash-mount holes simplify faucet swaps.
  • 18-gauge type 300 stainless steel top, bowls, sides, front apron & backsplash with #4 satin polish.
  • Heavy-duty 1-5/8" Ø stainless legs, side bracing & 1" bullet feet—level and rock solid.
  • Includes (4) 1-1/2" drains, basket strainers & overflow standpipes (PB-OVF-BS).
  • Pre-drilled side holes and supplied Z-clip speed installation & line-up with adjacent underbar pieces.
  • NSF listed for open food-service use.

Specifications

Overall size (W × D × H) 96" × 18" × 32 1/2"
Number of compartments 4
Bowl dimensions 10"W × 14"F/B × 10"D (each)
Drainboards (2) 24" L, left & right
Backsplash height 3"
Faucet mounting (2) splash plates, 4" centers, removable
Material & gauge 18-ga type 300 stainless steel
Legs / feet 1-5/8" SS legs with side bracing & 1" adjustable bullet feet
Drain connection 1-1/2" NPS male
Certifications NSF
Approx. ship weight 128 lb (plus packaging)

What’s Included

  • Slim-Line 4-compartment sink assembly
  • (4) Basket strainers & overflow standpipes
  • (4) Removable perforated drainboard inserts
  • (4) Stainless steel legs with hardware & side bracing
  • Z-clip wall mount & side-to-side joining hardware
  • Assembly & stainless-steel care instructions

Faucets, side splashes, and other accessories are sold separately. See compatible John Boos options below or chat with us for a custom underbar layout.

Why Choose John Boos?

  • Made in the USA since 1887
  • Factory-direct craftsmanship with strict NSF compliance
  • Field-friendly removable faucet plates & leg options for fast installs
  • Backed by expert support from our food-service equipment team
Installation Tip: Assemble legs & bracing while the unit is on its side, level the feet, secure the Z-clip to the wall, and connect plumbing before installing faucets.

Features & Specs

Manufacturer

John Boos

Brand_name

Slim-Line

Certifications

NSF, CSA-Sanitation

Height

32.5in

Width

96.0in

Depth

18.0in

Shipping Weight

128.0lbs

Top Stainless Series

300 series

Bowl Size

10" x 14" front-to-back

Bowl Depth (rim - drain)

10"

Sink Compartments

(4)

Width (side - side) OA

91" - 96"

Splash

3"

Drainboards

drainboards on left & right

Depth (front - back) OA

18" - 19"

Construction

stainless steel top, front, ends & legs

Specifications

Slim-Line Underbar Sink Unit, 4-compartment, 96"W x 18"D x 32-1/2"H overall size, (4) 10"W x 14" front-to-back x 10" deep compartments, 24" drainboard on left and right with removable perforated insert, 3"H backsplash, (2) sets of removable splash mount faucet holes with 4" centers, includes 1-1/2" drains & overflow stand pipes (PB-OVF-BS), 18/300 stainless steel construction, stainless steel legs & side bracing, adjustable stainless steel bullet feet, NSF, (weights are subject to additional packaging)
