John Boos UBS4-1872-2D12-X Slim-Line Bar Equipment
Description
John Boos Slim-Line Underbar 4-Compartment Sink
Model UBS4-1872-2D12 | 72" L × 18" D × 32-1/2" HBuilt for busy bars, cafés and tasting rooms that refuse to compromise on usable space, the 18 inch-deep Slim-Line series slides neatly into tight footprints while delivering full four-compartment washing power plus dual drainboards. Heavy-duty 18-gauge, type 300 stainless steel and NSF certification mean this unit is ready for high-volume, food-safe performance shift after shift.
Why you’ll love it
- Slim 18" front-to-back depth maximizes aisle clearance behind the bar.
- (4) 10" W × 14" F-B × 10" D sink bowls handle wash, rinse, sanitize & dump.
- 12" left & right drainboards with removable perforated inserts speed air-drying.
- Removable splash-mount faucet plates, pre-punched 4" on center, simplify install or future service.
- 3" high backsplash keeps moisture off adjacent walls and meets health codes.
- Includes 1-1/2" drains with basket strainers & overflow stand pipes (PB-OVF-BS).
- All-stainless construction: 18-ga. type 300 top, apron, sides, backsplash, legs & bracing.
- Adjustable stainless bullet feet level the sink on uneven floors.
- Standard side mounting holes allow you to bolt multiple Slim-Line pieces together for a seamless bar run.
- NSF listed for peace-of-mind sanitation compliance.
At-a-glance specifications
| Overall dimensions | 72" W × 18" D × 32-1/2" H |
|---|---|
| Bowl size (each) | 10" W × 14" F-B × 10" D |
| Drainboards | 12" left & 12" right, removable perforated inserts |
| Backsplash height | 3" |
| Faucet holes | (2) sets, splash-mount, 4" on center (plates removable) |
| Drain connection | 1-1/2" NPS, basket strainers & overflow stand pipes included |
| Material & finish | 18 ga. type 300 stainless steel, #4 satin polish |
| Legs & bracing | 1-5/8" Ø stainless legs, front-to-back side bracing, adjustable SS bullet feet |
| Net weight | Approx. 104 lb (weights subject to packaging) |
| Certifications | NSF listed |
Popular add-ons (sold separately)
- UBSS-18-L / UBSS-18-R – Slim-Line stainless side splashes
- PBF-4SM2-10LF – Heavy-duty 4" splash-mount faucet
- PBF-W2-10LF – Economy 4" splash-mount faucet
- PB-WL-36 – Flexible shallow-mount faucet hoses
Need help selecting faucets or speed rails? Chat with our equipment specialists for curated bar packages.
Stainless care made simple
Keep that signature John Boos satin shine by cleaning with non-chloride detergents, soft cloths and Bar Keepers Friend when needed. Rinse thoroughly and always wipe along the grain.
