John Boos UBDB-1836 Slim-Line Bar Equipment
Description
John Boos Slim-Line 36" Freestanding Underbar Drainboard
Model UBDB-1836 | 36"W × 18"D × 32-1/2"H | NSF ListedAdd a professional, space-saving drain station to your bar line-up. The Slim-Line series keeps every square inch working for you with a narrow 18" front-to-back footprint while delivering the rugged performance John Boos is known for.
Key Features
- 18 ga type 300 stainless steel top, sides, apron & backsplash – #4 satin finish.
- Slim 18" depth maximises aisle clearance without sacrificing capacity.
- Creased deck and 3" backsplash direct water to the top-mounted 1-3/8" drain.
- Removable perforated insert promotes rapid air-drying of glassware & bar tools.
- Bolt-on 1-5/8" stainless steel legs with 1" adjustable bullet feet for quick, level installation.
- 1-1/4" front-to-back bracing and side bracing add rock-solid stability.
- Pre-drilled side holes & supplied Z-clip let you bolt or wall-mount to adjacent underbar equipment.
- Front inserts are ready for single or double speed rails (sold separately).
- NSF certified for open food-service areas.
Technical Specifications
| Footprint (W × D) | 36" × 18" |
|---|---|
| Overall height | 32-1/2" (including backsplash) |
| Backsplash height | 3" |
| Drain opening | 1-3/8" with 1" MPT (1-1/2" L) connection |
| Insert | Removable perforated stainless steel grate |
| Material & finish | 18 ga type 300 SS, #4 polish (satin) |
| Legs / feet | 1-5/8" Ø SS legs • 1" adjustable SS bullet feet |
| Net weight | 51 lb (shipping weight may vary) |
| Certifications | NSF |
Popular Accessories (sold separately)
- UBSS-21-L / UBSS-21-R — Left or Right side splash guards
- UBSR1 Series — Single speed rails in 12", 18", 24", 30", 36"
- UBSR2 Series — Double speed rails in 12", 18", 24", 30", 36"
Care & Maintenance
- Clean daily with mild soap or non-chloride stainless cleanser; rinse and dry.
- Avoid abrasive pads, steel wool or harsh chemicals that contain chlorides.
- Restore shine with John Boos Stainless Steel Cleaner or Bar Keepers Friend.
Following the recommended care routine preserves the passive protective film on type 300 stainless steel and prevents corrosion or pitting.
