John Boos E-Series 3-Compartment Sink – 98-1/2" with 24" Left Drainboard

Model E3S8-24-14L24 | NSF & CSA-Sanitation Certified

Built for the daily grind of commercial kitchens, bars, bakeries and food-service commissaries, this rugged John Boos E-Series sink delivers generous washing capacity, easy sanitation and the long-term value professionals demand.

Key Features

  • Three 24" × 24" × 14" deep compartments – ideal for wash, rinse & sanitize cycles.
  • Integrated 24" left-side drainboard keeps clean or dirty wares organized and off the work surface.
  • 18 ga, Type 300 stainless steel top and bowls with #4 polished satin finish.
  • Full-length 9-3/4" boxed backsplash with 45° top edge and 2" return for a tight, sanitary wall seal.
  • (2) sets of 1-1/8" dia. splash-mount faucet holes on 8" centers – ready for dual faucets or sprayers.
  • 3-1/2" die-stamped drain openings for a leak-free fit (basket strainers sold separately).
  • Galvanized 1-5/8" Ø legs & gussets with adjustable plastic bullet feet for rock-solid stability.
  • All exposed welds TIG-welded & polished to match surrounding surfaces.
  • Bull-nosed edges and 3/4" radius coved bowl corners simplify cleanup and improve safety.

At-a-Glance Specifications

Overall size (W × D × H) 98-1/2" × 29-1/2" × 43-3/4"
Compartment (each) 24" W × 24" F-to-B × 14" D
Drainboard 24" left side, stamped & pitched for rapid drainage
Backsplash 9-3/4" H boxed, 45° top, 2" return
Faucet holes (2) sets, 8" centers, 1-1/8" dia.
Drain opening 3-1/2" dia. (die-stamped)
Material & finish 18 ga Type 300 stainless, #4 satin
Legs / feet Galvanized steel legs & gussets, adjustable plastic bullet feet
Weight Approx. 128 lb
Certifications NSF, CSA-Sanitation
Manufactured Effingham, Illinois, USA

Why Choose the John Boos E-Series?

  • Trusted heritage – John Boos has been crafting premium food-service equipment since 1887.
  • Cost-effective 18 ga build offers durability without the heavy price tag of 16 ga models.
  • Ships quickly from stock in Effingham for reduced lead times.
  • Supported by nationwide Boos service & parts network.

Care & Maintenance Tips

  • Clean daily with non-chloride cleanser (e.g. Bar Keepers Friend) and a soft cloth.
  • Rinse and wipe dry to maintain the chromium oxide protective layer.
  • Avoid abrasive pads, steel wool, or harsh chemicals containing chlorine or quaternary salts.
  • Apply John Boos Stainless Steel Cleaner as needed to restore luster.

Need the full stainless steel care guide? Download it from the Resources tab or contact us and we’ll send a copy.

Important: Faucet assemblies, basket strainers and overflow fittings are sold separately.

Overall Dimensions:

98.5"W x 29.5"D x 43.75"H

Product Weight:

128.0 lb
Manufacturer John Boos
Certifications ["NSF", "CSA-Sanitation"]
Height 43.75in
Width 98.5in
Depth 29.5in
Shipping Weight 128.0lbs
Overall Length 97" - 108"
Compartment (front - back) 24"
Base Type legs
Top Stainless Series 300 series
Sink Depth (rim - drain) 14"
Compartment Width (side - side) 24"
Drainboards with left-hand drainboard
Top Gauge 18 gauge
Base Construction galvanized
Splash Height 9-3/4"
Specifications E-Series Sink, 3-compartment, 98-1/2"W x 29-1/2"D x 43-3/4"H overall size, (3) 24"W x 24" front-to-back x 14" deep compartments, (1) 24" left drainboard, 9-3/4"H boxed backsplash with 45° top and 2" return, (2) sets of splash mount faucet holes with 8" centers, 3-1/2" diameter die-stamped drain openings, 18/300 stainless steel, galvanized legs & gussets, adjustable plastic bullet feet, NSF, CSA-Sanitation (Available in Effingham)

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Instructions PDF Download PDF Care & maintenance PDF Download
