John Boos E-Series 2-Compartment Sink w/ 24" Left Drainboard – Model E2S8-24-14L24

74-1/2" W × 29-1/2" D × 43-3/4" H | 18 ga Type 300 Stainless Steel

Engineered for demanding commercial kitchens, this John Boos E-Series sink pairs roomy 24" × 24" compartments with a full-size left-hand drainboard, delivering rugged performance and everyday value in one smart, NSF-listed package.

Key Features
  • Two 24" W × 24" F/B × 14" D compartments handle stock pots, sheet pans and bulky ware.
  • Integrated 24" left-side drainboard speeds drying and staging.
  • 18-gauge, Type 300 stainless steel top & bowls with #4 satin polish for superior corrosion resistance.
  • 3/4" radius interior corners for easy cleaning; bull-nosed exterior edges for operator safety.
  • 9-3/4" boxed backsplash with 2" 45° return protects surrounding walls.
  • Splash-mount faucet holes on 8" centers (1-1/8" Ø) accept most commercial faucets (sold separately).
  • (2) 3-1/2" die-stamped drain openings fit standard drains or disposers.
  • 1-5/8" Ø galvanized legs and gussets; adjustable 1" plastic bullet feet level on uneven floors.
  • TIG-welded construction; exposed welds polished to match adjacent surfaces.
  • NSF & CSA-Sanitation certified.
Dimensions & Specifications
Overall size 74-1/2" W × 29-1/2" D × 43-3/4" H (to top of backsplash)
Work height 36" to sink roll
Compartments (2) 24" W × 24" F/B × 14" D
Drainboard 24" W, left side
Backsplash 9-3/4" H boxed, 2" 45° return, 1" tile edge
Faucet mounting Splash-mount holes on 8" centers (1-1/8" Ø)
Drain openings 3-1/2" die-stamped
Material – top/bowls 18 ga Type 300 stainless steel, #4 finish
Legs / gussets Galvanized steel, 1-5/8" Ø
Feet Adjustable 1" plastic bullet feet
Shipping weight Approx. 96 lb
Certifications NSF, CSA-Sanitation
Perfect For
  • Full-service & quick-service restaurants
  • Cafeterias, schools & hospitals
  • Bakeries & commissaries
  • Food trucks and ghost kitchens needing a full-size warewashing station
Care & Cleaning

Clean daily with non-chloride detergents and soft cloths or plastic scouring pads. Always wipe in the direction of the steel’s polish lines, rinse thoroughly, and dry. Avoid abrasive cleansers, steel wool, and prolonged contact with saline or acidic solutions.

Important: Faucet, drains and other accessories are sold separately. Verify local plumbing codes before installation.

Overall Dimensions:

74.5"W x 29.5"D x 43.75"H

Product Weight:

96.0 lb
Manufacturer John Boos
Certifications ["NSF", "CSA-Sanitation"]
Height 43.75in
Width 74.5in
Depth 29.5in
Shipping Weight 96.0lbs
Compartment Width (side - side) 24"
Top Gauge 18 gauge
Drainboards with left-hand drainboard
Compartment (front - back) 24"
Base Construction galvanized
Overall Length 73" - 90"
Sink Depth (rim - drain) 14"
Base Type legs
Splash Height 9-3/4"
Top Stainless Series 300 series
Specifications E-Series Sink, 2-compartment, 74-1/2"W x 29-1/2"D x 43-3/4"H overall size, (2) 24"W x 24" front-to-back x 14" deep compartments, (1) 24" left drainboard, 9-3/4"H boxed backsplash with 45° top and 2" return, (1) set of splash mount faucet holes with 8" centers, 3-1/2" die-stamped drain openings, 18/300 stainless steel construction, galvanized legs & gussets, adjustable plastic bullet feet, NSF, CSA-Sanitation
