John Boos 4PB3024-1D30R Pro-Bowl Compartment Sinks
$5,183.62
Unit price
/
Unavailable
Description
John Boos Pro-Bowl 4-Compartment Sink with 30" Right Drainboard – 154" x 29-1/2"
Model 4PB3024-1D30R | NSF & CSA-Sanitation ListedGive your dish room a serious upgrade. The John Boos Pro-Bowl series combines oversized bowl capacity, rugged 16-gauge stainless steel and smart ergonomic details to keep high-volume kitchens moving fast and staying sanitary.
Key Features
- (4) spacious compartments – 30" L x 24" W x 12" D each
- Generous 30" right-hand drainboard for rinsing, drying & staging
- Heavy-duty 16-gauge, Type 300 stainless steel with #4 satin finish
- 10" boxed backsplash with 45° top & 2" return protects walls
- (2) sets of splash-mount faucet holes, 8" on-center (1" Ø)
- 3-1/2" die-stamped drain openings accept standard basket strainers
- 1-5/8" Ø stainless steel legs with adjustable front & side bracing
- Leveling made easy with stainless steel bullet feet
- 5/8" coved interior corners & bull-nosed edges for quick, thorough cleaning
- Ships knocked-down to cut freight costs; simple on-site assembly
- NSF & CSA-Sanitation certified for code compliance
Dimensions & Specifications
| Overall width (L) | 154-3/16" |
|---|---|
| Overall depth (W) | 29-1/2" |
| Overall height | 44-1/16" (to top of backsplash) |
| Working height | 36-5/16" (to sink roll) |
| Compartment count | 4 |
| Compartment size | 30" L x 24" W x 12" D (each) |
| Drainboard | 30" – right side |
| Backsplash | 10" H boxed, 45° top, 2" return |
| Material thickness | 16-gauge (1.5 mm) |
| Material type | Type 300 stainless steel, #4 finish |
| Faucet holes | (2) sets, 8" on-center |
| Drain openings | 3-1/2" Ø die-stamped |
| Shipping configuration | Knocked-down (KD) |
| Approx. shipping weight | 227 lb |
| Certifications | NSF, CSA-Sanitation |
Need faucets, lever waste valves or overshelves? Pair this sink with genuine John Boos accessories for a turnkey warewashing station.
Care & Maintenance
- Clean daily with non-chloride detergents and a soft cloth or sponge.
- Always wipe and polish along the grain to preserve the satin finish.
- Avoid abrasive pads and chlorine bleach, which can damage stainless steel.
- Use Bar Keepers Friend or John Boos Stainless Steel Cleaner for stubborn stains, then rinse and dry completely.
Important: Standing water, food acids or salt left on stainless steel can lead to pitting or discoloration. Rinse and dry the surface promptly for longest service life.
Features & Specs
Features & Specs
Manufacturer
John Boos
Brand_name
Pro-Bowl
Certifications
NSF, CSA-Sanitation
Height
44.06in
Width
154.19in
Depth
29.5in
Shipping Weight
227.0lbs
Drainboards
with right-hand drainboard
Base Construction
stainless steel
Overall Length
130" - 198"
Top Stainless Series
300 series
Compartment (front - back)
24"
Compartment Width (side - side)
30"
Splash Height
10"
Top Gauge
16 gauge
Sink Depth (rim - drain)
12"
Base Type
legs with front & side crossrails
Specifications
Pro-Bowl Sink, 4-compartment, 154-3/16"W x 29-1/2"D x 44-1/16"H overall size, (4) 30"W x 24" front-to-back x 12" deep compartments, (1) 30" right drainboard, 10"H boxed backsplash with 45° top & 2" return, (2) sets of splash mount faucet holes with 8" centers, 3-1/2" die-stamped drain openings, 16/300 stainless steel construction, stainless steel legs, adjustable front & side bracing, adjustable bullet feet, NSF, CSA-Sanitation, KD
