John Boos 4PB244-1D30L Pro-Bowl Compartment Sinks
$4,540.15
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
John Boos 4PB244-1D30L Pro-Bowl Compartment Sinks is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
John Boos 4PB244-1D30L Pro-Bowl Compartment Sinks
$4,540.15
Unit price
/
Unavailable
Description
John Boos Pro-Bowl 4-Compartment Sink – 30" Left Drainboard
Model 4PB24-1D30L | 130 3/16" W x 29 1/2" D x 44 1/16" HBuilt from 16-gauge, Type 300 stainless steel, the Pro-Bowl 4-compartment sink gives high-volume kitchens a dedicated bay for every stage of the ware-washing process—plus an oversized drainboard that keeps clean ware moving.
Key Features
- (4) spacious 24" W x 24" F-B x 14" D bowls with 5/8" radius coved corners
- 30" left-side drainboard pitched for fast drainage & staging
- 10" high boxed backsplash with 45° top & 2" return for a sanitary wall seal
- (2) sets of splash-mount faucet holes on 8" centers (1" Ø)
- 3-1/2" die-stamped drain openings accept standard strainers/lever wastes
- TIG-welded seams; exposed welds polished to a smooth #4 satin finish
- 1-5/8" Ø stainless legs with adjustable front & side bracing
- 1" adjustable stainless bullet feet level the sink on uneven floors
- Ships knocked-down (KD) to reduce freight costs and fit through tight doorways
- NSF & CSA-Sanitation listed
At-a-Glance Specifications
| Overall width | 130 3/16" |
|---|---|
| Overall depth | 29 1/2" |
| Overall height | 44 1/16" (36 5/16" to sink roll) |
| Compartment size (ea.) | 24" W x 24" F-B x 14" D |
| Drainboard | 30" L, left-mounted |
| Backsplash | 10" H boxed w/ 2" return |
| Gauge / material | 16-ga Type 300 stainless steel, #4 satin |
| Faucet holes | (2) sets, 8" centers, splash-mount |
| Drain openings | 3-1/2" Ø die-stamped |
| Legs & feet | Stainless legs, adj. bracing & 1" bullet feet |
| Certifications | NSF, CSA-Sanitation |
| Shipping weight | ≈ 197 lb (KD) |
Why Choose a Pro-Bowl?
- Over 135 years of John Boos manufacturing expertise
- Engineered for continuous, high-volume service
- Compatible with Boos add-on faucets, lever wastes, overshelves & pot racks
Care & Maintenance
- Clean daily with mild detergent or non-chloride stainless cleanser.
- Avoid abrasive pads, wire brushes, or cleaners containing chlorides.
- Rinse & towel-dry after each use to preserve the corrosion-resistant finish.
- Polish periodically with John Boos Stainless Steel Cleaner for a like-new sheen.
Note: Faucets, drains, lever wastes and other accessories are sold separately.
Always verify local plumbing codes before installation.
Features & Specs
Features & Specs
Manufacturer
John Boos
Brand_name
Pro-Bowl
Certifications
NSF, CSA-Sanitation
Height
44.06in
Width
130.19in
Depth
29.5in
Shipping Weight
212.0lbs
Base Construction
stainless steel
Splash Height
10"
Top Stainless Series
300 series
Compartment Width (side - side)
24"
Base Type
legs with front & side crossrails
Sink Depth (rim - drain)
14"
Drainboards
with left-hand drainboard
Compartment (front - back)
24"
Top Gauge
16 gauge
Overall Length
130" - 198"
Specifications
Pro-Bowl Sink, 4-compartment, 130-3/16"W x 29-1/2"D x 44-1/16"H overall size, (4) 24"W x 24" front-to-back x 14" deep compartments, (1) 30" left drainboard, 10"H boxed backsplash with 45° top & 2" return, (2) sets of splash mount faucet holes with 8" centers, 3-1/2" die-stamped drain openings, 16/300 stainless steel construction, stainless steel legs, adjustable front & side bracing, adjustable bullet feet, NSF, CSA-Sanitation, KD
