John Boos 4PB204-2D24 Pro-Bowl Compartment Sinks
Description
John Boos “Pro-Bowl” 4-Compartment Sink – 131-1/4″ W
Model 4PB204-2D24 • Dual 24″ Drainboards • NSF & CSA-Sanitation ListedEngineered for nonstop commercial duty, the John Boos Pro-Bowl 4-compartment sink combines heavy-gauge stainless steel durability with generous working room for high-volume ware-washing, prep, and sanitizing tasks. Its knocked-down design ships economically and assembles quickly on site, making it the go-to solution for restaurants, commissaries, cafeterias, and more.
Key Features
- (4) spacious 20″ W × 20″ F-B × 14″ D compartments streamline wash, rinse, sanitize & soak steps
- Rugged 16-gauge Type 300 stainless steel top, bowls & apron with easy-clean #4 satin finish
- Full-length 10″ boxed backsplash with 45° return and ¾″ turned-down rear lip keeps walls dry
- (2) 24″ sloped drainboards (left & right) speed drying and staging
- (2) sets splash-mount faucet holes, 8″ on-center, let you mount pre-rinse + fill faucets together
- 3-½″ die-stamped drain openings fit standard sink strainers or lever-waste systems
- 1-⅝″ O.D. stainless legs with adjustable 1-¼″ bracing deliver rock-solid stability
- Adjustable stainless bullet feet level the sink on uneven floors
- Ships knocked down (KD) for lower freight costs; simple field assembly
- NSF & CSA-Sanitation certified for code-compliant installation
At-a-Glance Specifications
| Model # | 4PB204-2D24 |
|---|---|
| Overall Size (W × D × H) | 131 - 1/4″ × 25 - 1/2″ × 44 - 1/16″ |
| Bowl Size (each) | 20″ W × 20″ F-B × 14″ D |
| Drainboards | (2) × 24″, left & right |
| Backsplash | 10″ high boxed with 2″ return & 45° top |
| Material | 16 GA Type 300 stainless steel, #4 satin polish |
| Faucet Mount | Splash-mount, 8″ centers, 1″ Ø holes (two sets) |
| Drain Opening | 3-½″ die-stamped |
| Legs / Bracing | 1-⅝″ O.D. legs, 1-¼″ O.D. adjustable front & side bracing (stainless) |
| Feet | Adjustable stainless bullet feet |
| Certifications | NSF, CSA-Sanitation |
| Ship Weight | ≈ 190 lb (knocked down) |
Ideal Applications
- High-volume restaurants & ghost kitchens
- School, hospital & corporate cafeterias
- Breweries, bakeries & food-production facilities
Need faucets, lever wastes, end-splashes, or an overshelf? Compatible John Boos accessories are available—contact us for a custom quote.
