John Boos  |  Pro-Bowl  |  SKU: 4PB204-1D18R

John Boos 4PB204-1D18R Pro-Bowl Compartment Sinks

$3,598.43
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

John Boos “Pro-Bowl” 4-Compartment Sink – 102-3/16″ W x 25-1/2″ D

Model 4PB204-1D18R | 16 GA Type 300 Stainless Steel | 18″ Right Drainboard

Engineered for high-volume food-service operations, the Pro-Bowl series delivers uncompromising durability and sanitation. Four spacious 14-inch-deep compartments and an integrated 18-inch drainboard let busy kitchens wash, rinse, sanitize and air-dry without missing a beat.

Built for the Rush
  • 16-gauge, Type 300 stainless steel with #4 satin finish resists corrosion & cleans fast
  • (4) 20″ W x 20″ F/B x 14″ D bowls formed with 5/8″ radius corners for easy wipe-down
  • 18″ right-hand drainboard slopes for positive drainage and added prep space
  • 10″ boxed backsplash with 45° rolled top & 2″ return protects walls from overspray
  • (2) sets of 8″-on-center splash-mount faucet holes (1″ diameter) accept pre-rinse or add-a-faucet assemblies
  • 3-1/2″ die-stamped drain openings fit standard basket strainers or lever-wastes
  • All exposed edges bull-nosed and TIG-welded seams polished to match adjacent surfaces
  • Heavy-duty 1-5/8″ Ø stainless steel legs with adjustable front & side bracing
  • 1″ stainless bullet feet level the sink on uneven floors
  • NSF & CSA-Sanitation listed; ships knocked-down (KD) to minimize freight costs
Technical Specifications
Model 4PB204-1D18R
Compartments (4) 20″ W x 20″ F/B x 14″ D
Overall Dimensions (W × D × H) 102-3/16″ W × 25-1/2″ D × 44-1/16″ H (to top of backsplash)
Drainboard 18″ right side, integrally welded
Backsplash 10″ high boxed style, 45° top, 2″ return
Faucet Holes (2) sets, 8″ centers, 1″ Ø
Drain Openings (4) 3-1/2″ die-stamped
Material & Finish 16 GA Type 300 SS, #4 satin
Legs / Bracing / Feet Stainless steel legs (1-5/8″ Ø) with adjustable SS cross-bracing & 1″ bullet feet
Certifications NSF, CSA-Sanitation
Ship Weight Approx. 170 lb (KD)

Faucets, drains, and overflow assemblies are sold separately. Field assembly required; all hardware included.

Features & Specs

Manufacturer

John Boos

Brand_name

Pro-Bowl

Certifications

NSF, CSA-Sanitation

Height

44.06in

Width

102.19in

Depth

25.5in

Shipping Weight

170.0lbs

Top Stainless Series

300 series

Splash Height

10"

Base Construction

stainless steel

Drainboards

with right-hand drainboard

Compartment (front - back)

20"

Sink Depth (rim - drain)

14"

Overall Length

98" - 113"

Compartment Width (side - side)

20"

Base Type

legs with front & side crossrails

Top Gauge

16 gauge

Specifications

Pro-Bowl Sink, 4-compartment, 102-3/16"W x 25-1/2"D x 44-1/16"H overall size, (4) 20"W x 20" front-to-back x 14" deep compartments, (1) 18" right drainboard, 10"H boxed backsplash with 45° top & 2" return, (2) sets of splash mount faucet holes with 8" centers, 3-1/2" die-stamped drain openings, 16/300 stainless steel construction, stainless steel legs, adjustable front & side bracing, adjustable bullet feet, NSF, CSA-Sanitation, KD
