John Boos 4PB204-1D18L Pro-Bowl Compartment Sinks
$3,598.43
Unit price
/
Unavailable
Description
John Boos Pro-Bowl 4-Compartment Sink – 102" x 25-1/2"
Model 4PB204-1D18L • AutoQuotes ID 4814Engineered for demanding commercial kitchens, the John Boos Pro-Bowl series pairs heavy-duty 16-gauge stainless steel with smart, sanitary design features that keep your dish room running smoothly shift after shift.
Key Features
- (4) spacious 20" W x 20" F/B x 14" D compartments tackle prep, soak, wash, and rinse tasks simultaneously.
- 18" left-side drainboard provides a generous landing area for dirty or clean wares.
- One-piece TIG-welded top with #4 satin polish resists corrosion and wipes clean fast.
- 10" boxed backsplash with 45° return contains splashes; pre-punched for (2) splash-mount faucets on 8" centers.
- 3-1/2" die-stamped drain openings accept standard lever or twist-waste drains.
- All vertical & horizontal corners coved to a 5/8" radius for effortless sanitizing.
- 1-5/8" O.D. stainless steel legs with adjustable front & side bracing maximize stability.
- Adjustable stainless steel bullet feet level the sink on uneven floors.
- Ships knocked down (KD) to reduce freight costs and ease delivery through tight spaces.
- NSF and CSA-Sanitation listed for hassle-free code compliance.
At-a-Glance Specifications
| Series / Model | Pro-Bowl • 4PB204-1D18L (left drainboard) |
|---|---|
| Compartments | 4 |
| Bowl Size (each) | 20" W x 20" F/B x 14" D |
| Overall Dimensions | 102-3/16" W x 25-1/2" D x 44-1/16" H |
| Drainboard | 18" length, left side |
| Backsplash | 10" H boxed, 2" return, 45° top |
| Faucet Holes | (2) sets, 8" on-center, 1" dia. |
| Drain Openings | 3-1/2" dia., die-stamped |
| Material / Gauge | 16 ga Type 300 stainless steel |
| Legs & Bracing | Stainless steel legs, adjustable front & side bracing |
| Feet | Adjustable stainless steel bullet feet |
| Certifications | NSF, CSA-Sanitation |
| Approx. Ship Weight | 170 lb |
Installation Note: Faucet sets, drains, and plumbing connections are sold separately. Because this unit ships knocked down, assembly and field connection must be completed by a qualified installer.
Looking for compatible faucets or lever-waste drains? Contact our equipment specialists—we’re here to help.
Features & Specs
Features & Specs
Manufacturer
John Boos
Brand_name
Pro-Bowl
Certifications
NSF, CSA-Sanitation
Height
44.06in
Width
102.19in
Depth
25.5in
Shipping Weight
170.0lbs
Splash Height
10"
Base Type
legs with front & side crossrails
Compartment Width (side - side)
20"
Overall Length
98" - 113"
Sink Depth (rim - drain)
14"
Drainboards
with left-hand drainboard
Base Construction
stainless steel
Top Gauge
16 gauge
Top Stainless Series
300 series
Compartment (front - back)
20"
Specifications
Pro-Bowl Sink, 4-compartment, 102-3/16"W x 25-1/2"D x 44-1/16"H overall size, (4) 20"W x 20" front-to-back x 14" deep compartments, (1) 18" left drainboard, 10"H boxed backsplash with 45° top & 2" return, (2) sets of splash mount faucet holes with 8" centers, 3-1/2" die-stamped drain openings, 16/300 stainless steel construction, stainless steel legs, adjustable front & side bracing, adjustable bullet feet, NSF, CSA-Sanitation, KD
