John Boos 4PB20-1D30R Pro-Bowl Compartment Sinks
Description
John Boos “Pro-Bowl” 4-Compartment Sink with 30" Right Drainboard
Model 4PB20-1D30R | NSF & CSA-Sanitation ListedEngineered for high-volume food-service operations, the John Boos Pro-Bowl 4-compartment sink delivers rugged durability, generous working room and the hygiene assurance you expect from a leader in commercial stainless fabrication. 16-gauge Type 300 stainless steel, coved corners and a full 10" boxed backsplash make cleanup fast and sanitary, while the extra-large 30" drainboard keeps dishes or vegetables moving down the line.
Key Features
- Four 20" W × 20" D × 12" H bowls – perfect for wash, rinse, sanitize & dump setups
- 30" right-hand drainboard with positive pitch for fast water run-off
- Heavy-duty 16 GA, Type 300 stainless steel with #4 satin polish
- 10" boxed backsplash with 45° top edge & 2" return to wall
- Two sets of 8" on-center splash-mount faucet holes (1" Ø)
- 3-1/2" die-stamped NSF drain openings—ready for standard basket strainers or lever wastes
- 1-5/8" O.D. stainless steel legs with adjustable bullet feet
- Adjustable 1-1/4" O.D. front & side stainless bracing for added rigidity
- All vertical & horizontal corners coved to a 5/8" radius for effortless cleaning
- Bull-nosed front & side edges for operator safety and a polished, finished look
- Shipped KD (knocked-down) to lower freight costs and expedite job-site entry
Technical Specifications
| Overall dimensions | 114-3/16" W × 25-1/2" D × 44-1/16" H (to top of backsplash) |
|---|---|
| Compartments (qty 4) | 20" W × 20" F/B × 12" D |
| Drainboard | 30" right side, pitched & rib-reinforced |
| Backsplash | 10" H boxed style, 2" return, 45° top |
| Faucet holes | (2) sets, 8" centers, 1" Ø |
| Drain openings | 3-1/2" die-stamped (NSF) |
| Material / gauge | 16 GA Type 300 series stainless, #4 satin |
| Legs / feet | 1-5/8" O.D. stainless legs, adjustable stainless bullet feet |
| Bracing | Adjustable front & side, 1-1/4" O.D. stainless |
| Certifications | NSF / ANSI 2, CSA B45.4 Sanitation |
| Shipping configuration | Knocked-down (KD) base; simple on-site assembly |
Faucets, drains, and other accessories are sold separately so you can configure the station to your operation’s exact needs.
