John Boos 4PB20-1D30L Pro-Bowl Compartment Sinks
Description
John Boos Pro-Bowl 4-Compartment Sink with 30" Left Drainboard
Model 4PB20-1D30L | 16 GA Type 300 Stainless SteelTackle the heaviest cleaning cycles with the John Boos Pro-Bowl 4-Compartment Sink. Built from rugged 16-gauge stainless steel and finished in a sanitary #4 satin polish, this NSF-listed workhorse combines four generous 20" x 20" x 12" bowls, a spacious 30" left-side drainboard, and a full 10" boxed backsplash to keep your kitchen running smoothly and safely.
Key Features
- Overall dimensions: 114-3/16" W x 25-1/2" D x 44-1/16" H
- (4) 20" W x 20" front-to-back x 12" deep compartments for wash, rinse, sanitize & soak
- 30" left drainboard with pitched surface for fast water run-off
- 10" boxed backsplash with 45° top and 2" return to wall
- (2) sets of splash-mount faucet holes, 8" on-center (1" Ø)
- 3-1/2" die-stamped drain openings ready for basket strainers or lever waste (sold separately)
- All bowl corners coved to a 5/8" radius for effortless cleaning
- Exposed edges bull-nosed for a safer, professional finish
- 1-5/8" O.D. stainless legs with adjustable front & side bracing
- 1" adjustable stainless steel bullet feet for precise leveling on uneven floors
- Ships knocked-down (KD) to minimize freight costs and fit through tight doorways
- NSF & CSA-Sanitation certified for food-service applications
Specifications
| Model | 4PB20-1D30L (Left Drainboard) |
|---|---|
| Compartments | 4 |
| Bowl size (W x F-B x Depth) | 20" × 20" × 12" |
| Drainboard | 30" (left side) |
| Overall size (W x D x H) | 114-3/16" × 25-1/2" × 44-1/16" |
| Backsplash | 10" H boxed with 2" return |
| Faucet holes | 2 sets, 8" on-center, 1" Ø |
| Drain openings | 3-1/2" die-stamped |
| Steel gauge / type | 16-GA, Type 300 stainless |
| Finish | #4 satin polish |
| Legs & bracing | Stainless legs (1-5/8" O.D.) with 1-1/4" O.D. stainless side/front bracing |
| Feet | 1" adjustable stainless bullet feet |
| Certifications | NSF, CSA-Sanitation |
Looking for faucets, lever waste assemblies, or end splashes? Reach out to our team for compatible accessories and custom configurations.
