John Boos  |  Pro-Bowl  |  SKU: 4PB184-1D24L

John Boos 4PB184-1D24L Pro-Bowl Compartment Sinks

$3,468.64
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

John Boos “Pro-Bowl” 4-Compartment Sink – 24" Left Drainboard

Model 4PB184-1D24L | 100-3/16" W x 23-1/2" D x 44-1/16" H

Built to keep even the busiest prep line moving, the John Boos Pro-Bowl 4-compartment sink delivers rugged, 16-gauge Type 300 stainless-steel performance with the layout today’s commercial kitchens demand—four full-size bowls plus a spacious 24-inch left-side drainboard.

Key Features

  • Four 18" W x 18" F-B x 14"-deep compartments for high-volume washing, rinsing, sanitizing & prep.
  • Integrated 24" drainboard (left side) speeds drying and staging.
  • 10" boxed backsplash with 45° return protects walls; 2" turn-down lip for a tight, sanitary fit.
  • (2) splash-mount faucet hole sets on 8" centers—ready for pre-rinse and fill faucets.
  • 3-1/2" die-stamped drain openings for a positive, leak-free fit with common commercial drain baskets.
  • 16-gauge, Type 300 stainless-steel top, bowls & apron with #4 satin polish—tough, easy to clean, NSF listed.
  • Stainless-steel legs with adjustable front & side bracing maximize strength while keeping the area open beneath.
  • 1" stainless adjustable bullet feet level the sink on uneven floors.
  • Ships knock-down (KD) for easier access through doorways and reduced freight costs.
  • NSF & CSA-Sanitation certified.

Specifications

Overall width (left to right) 100 3/16"
Overall depth (front to back) 23 1/2"
Overall height 44 1/16" (to top of backsplash)
Compartments (4) 18" W x 18" F-B x 14" D
Drainboard 24" L (left side)
Backsplash 10" H boxed with 2" return
Faucet mounting (2) 8"-on-center splash-mount hole sets, 1" dia.
Material / gauge 16-ga Type 300 stainless steel, #4 satin finish
Legs & bracing 1-5/8" O.D. stainless legs, 1-1/4" O.D. stainless bracing
Feet 1" dia. stainless adjustable bullet feet
Certifications NSF, CSA-Sanitation
Ship weight (approx.) 154 lb
Configuration Ships knock-down (KD) – simple field assembly

Ideal For

  • Restaurants, cafeterias & ghost kitchens with high ware-washing volume
  • Commissaries & food-prep facilities requiring multiple wash stages
  • School, hospital & institutional kitchens following HACCP segregation

Care & Maintenance

  • Rinse and wipe dry after each use—standing water and food acids shorten the life of stainless steel.
  • Clean with non-chloride detergents and soft cloths or plastic scouring pads.
  • Avoid harsh abrasives, wire brushes or bleach. For stubborn residue, Bar Keepers Friend is recommended.
  • Polish periodically with John Boos Stainless Steel Cleaner to restore the factory satin sheen.

Need a matching faucet, lever waste or overshelf? Shop compatible accessories.

Important: Faucet assemblies, basket strainers and overflow fittings are sold separately. Professional installation is recommended to ensure code compliance and optimal performance.

Features & Specs

Manufacturer

John Boos

Brand_name

Pro-Bowl

Certifications

NSF, CSA-Sanitation

Height

44.06in

Width

100.19in

Depth

23.5in

Shipping Weight

154.0lbs

Splash Height

10"

Compartment (front - back)

18"

Sink Depth (rim - drain)

14"

Base Type

legs with front & side crossrails

Compartment Width (side - side)

18"

Top Stainless Series

300 series

Base Construction

stainless steel

Top Gauge

16 gauge

Overall Length

98" - 113"

Drainboards

with left-hand drainboard

Specifications

Pro-Bowl Sink, 4-compartment, 100-3/16"W x 23-1/2"D x 44-1/16"H overall size, (4) 18"W x 18" front-to-back x 14" deep compartments, (1) 24" left drainboard, 10"H boxed backsplash with 45° top & 2" return, (2) sets of splash mount faucet holes with 8" centers, 3-1/2" die-stamped drain openings, 16/300 stainless steel construction, stainless steel legs, adjustable front & side bracing, adjustable bullet feet, NSF, CSA-Sanitation, KD
