John Boos

John Boos Pro-Bowl 4-Compartment Stainless Steel Sink with 30-Inch Right Drainboard and 14-Inch Deep Bowls

SKU: 4PB18244-1D30R
$3,820.41
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

4-compartment Sinks Best Sellers Commercial Plumbing Supplies Commercial Sinks Compartment Sinks John Boos New Arrivals Restaurant Equipment Sinks & Handwashing Stations

John Boos Pro-Bowl 4-Compartment Stainless Steel Sink with 30-Inch Right Drainboard and 14-Inch Deep Bowls

106-3/16"W x 29-1/2"D x 44-1/16"H Overall | 16-Gauge Type 300 Stainless Steel | Knocked Down

Built for high-volume dishroom workflows, this four-compartment sink combines deep bowls, a spacious right-side drainboard, and durable stainless steel construction.

  • Four 18" W x 24" front-to-back x 14" deep compartments support wash, rinse, sanitize, and prep tasks.
  • 30" right-hand drainboard provides a convenient landing and drying area.
  • 10" boxed backsplash with 45° top and 2" return helps control splash and protect the wall.
  • 16-gauge Type 300 stainless steel construction with stainless steel base components for durability.
  • Stainless steel legs, front and side bracing, and adjustable bullet feet provide a stable working platform.
  • 3-1/2" die-stamped drain openings and coved bowl corners promote drainage and easier cleaning.
  • Dual sets of 8" on-center splash-mount faucet holes and 1" backsplash faucet holes simplify faucet setup.
  • Ships knocked down for easier handling and installation.

Overall Dimensions:

106.19"W x 29.5"D x 44.06"H

Product Weight:

180.0 lb

Four-Compartment Layout

Includes four large bowls sized 18" wide x 24" front-to-back x 14" deep for multi-step sink workflows.

Right-Hand Drainboard

A 30" drainboard on the right side adds landing space for wet or clean wares.

10-Inch Boxed Backsplash

Backsplash includes a 45° top and 2" return to the wall to help reduce splash behind the sink.

Stainless Steel Construction

Built from 16-gauge Type 300 stainless steel with a #4 polish satin finish for long-lasting use.

Sanitary Bowl Design

Coved corners and bowl bottoms formed for drainage help simplify cleaning and water runoff.

Stainless Steel Base Support

Features stainless steel legs, front and side bracing, gussets, and adjustable bullet feet for stability.

Faucet Hole Configuration

Two sets of splash-mount faucet holes spaced 8" on center plus 1" backsplash faucet holes.

Knocked-Down Shipment

Ships KD to make transport and on-site handling easier.

Type Compartment Sink
Style Pro-Bowl
Installation Type Floor Model
Compartments 4
Material Stainless Steel
Finish #4 Polish, Satin Finish
Shipping Width 107 Inches
Shipping Depth 30 Inches
Shipping Height 45 Inches
Shipping Weight 180 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Care & maintenance PDF Download PDF Instructions PDF Download

Frequently Asked Questions

The overall size is 106-3/16"W x 29-1/2"D x 44-1/16"H.
It has four compartments, each measuring 18" wide x 24" front-to-back x 14" deep.
This model has a 30" right-hand drainboard, and the series requires specifying left or right drainboard orientation.
It is constructed of 16-gauge Type 300 stainless steel with stainless steel base components.
It includes two sets of splash-mount faucet holes spaced 8" on center, plus 1" faucet holes in the backsplash.
No. It ships knocked down (KD) for easier transport and handling.
