John Boos

John Boos Pro-Bowl 4-Compartment Commercial Stainless Steel Sink with Left and Right Drainboards, 18 x 24 x 12 Inch Bowls

SKU: 4PB1824-2D30
GTIN: 662969683405
$4,194.73
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

4-compartment Sinks Best Sellers Commercial Plumbing Supplies Commercial Sinks Compartment Sinks John Boos New Arrivals Restaurant Equipment Sinks & Handwashing Stations

John Boos Pro-Bowl 4-Compartment Commercial Stainless Steel Sink with Left and Right Drainboards, 18 x 24 x 12 Inch Bowls

135-1/4" W x 29-1/2" D x 44-1/16" H overall size; 10" boxed backsplash

A rugged four-compartment sink with dual drainboards, a tall backsplash, and heavy-duty stainless steel construction for high-volume kitchen workflows.

  • Four 18" W x 24" front-to-back x 12" deep compartments support washing, rinsing, and sanitizing tasks.
  • 30" left and right drainboards provide convenient staging and drying space.
  • 10" boxed backsplash with a 45° top and 2" return helps reduce splashback.
  • 16-gauge Type 300 stainless steel top with stainless steel legs and bracing is built for durability.
  • Adjustable bullet feet help level the sink during installation.
  • Knock-down construction makes shipping and assembly easier.

Overall Dimensions:

135.25"W x 29.5"D x 44.06"H

Product Weight:

189.0 lb

Four-Compartment Layout

Provides four separate wash stations, each sized 18" wide x 24" front-to-back x 12" deep.

Dual 30 Inch Drainboards

Left and right drainboards add usable landing space for dirty ware, clean ware, or prep support.

10 Inch Boxed Backsplash

The tall backsplash includes a 45° top and 2" return to help contain splashes and protect the wall.

16 Gauge Stainless Steel Top

Built with 16-gauge Type 300 stainless steel for commercial durability.

Stainless Steel Base and Bracing

Includes stainless steel legs, adjustable front and side bracing, and adjustable bullet feet for stable support.

Splash-Mount Faucet Holes

Equipped with two sets of splash-mount faucet holes on 8" centers, plus 1" faucet holes in the backsplash.

3-1/2 Inch Die-Stamped Drain Openings

Die-stamped drain openings are formed into the bowl bottoms for drainage.

Knock-Down Construction

Ships knocked down for easier transport and assembly.

Type Compartment Sink
Style 4 Compartment, With Left and Right Drainboards
Installation Type Floor Model
Compartments 4
Material Stainless Steel
Finish #4 Polish, Satin Finish
Top Gauge 16 Gauge
Compartment Width 18 Inches
Compartment Depth 24 Inches
Bowl Depth 12 Inches
Backsplash Height 10 Inches
Drain Opening Size 3-1/2 Inches
Faucet Hole Centers 8 Inches On Center
Base Type Legs with Front and Side Crossrails
Selling Unit Each
Units Per Case 1
Shipping Width 136 Inches
Shipping Depth 30 Inches
Shipping Height 45 Inches
Shipping Weight 189 Pounds

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Instructions PDF Download PDF Care & maintenance PDF Download

Frequently Asked Questions

It has 4 compartments.
Each compartment measures 18" wide x 24" front-to-back x 12" deep.
Yes. It includes 30" drainboards on both the left and right sides.
It includes two sets of splash-mount faucet holes with 8" centers and 1" faucet holes in the backsplash.
No. It is a knock-down (KD) unit for shipping and assembly.
