John Boos 4PB1824-1D30R Pro-Bowl Compartment Sinks
Description
John Boos “Pro-Bowl” 4-Compartment Sink – 30" Right Drainboard
Model 4PB1824-1D30R | 16 GA Type 300 Stainless SteelEngineered for the busiest prep and wash lines, the John Boos Pro-Bowl 4-compartment sink delivers heavy-duty performance, generous capacity and long-term sanitation you can trust. Its 106 ⅛ inch wide deck, four 18 × 24 in bowls and extra-large 30 inch right-hand drainboard give your team all the space they need to rinse, wash, sanitize and air-dry at top speed.
Highlights
- Four 18" W × 24" F/B × 12" D bowls – ideal for standard wash/rinse/sanitize workflows plus dedicated thaw or soak station.
- 30" right-side drainboard with pitched surface for fast water run-off.
- 10" boxed backsplash with 45° top & 2" return protects surrounding walls.
- Two sets of 8" o/c splash-mount faucet holes – mount pre-rinse & fill faucets exactly where you need them.
- 3 ½" die-stamped drain openings – ready for common lever- or twist-waste drains (drains sold separately).
- Rugged 16 ga, Type 300 stainless steel top and bowls with #4 satin polish.
- 1 ⅝" round stainless legs, adjustable front & side bracing and 1" bullet feet for rock-solid leveling.
- All interior & exterior corners coved or bull-nosed for effortless clean-ups.
- Ships knocked-down (KD) for easier access through narrow doorways – quick, bolt-together assembly on site.
At-a-Glance Specs
| Overall width (left → right) | 106 3/16" |
|---|---|
| Overall depth (front → back) | 29 1/2" |
| Overall height | 44 1/16" (to top of backsplash) |
| Compartment size × qty | (4) 18" W × 24" F/B × 12" D |
| Drainboard | 30" – right side |
| Backsplash | 10" H boxed, 45° return, 2" turn-down |
| Material & gauge | 16 ga Type 300 series stainless steel |
| Legs / bracing | 1 ⅝" O.D. stainless legs, 1 ¼" O.D. stainless bracing |
| Feet | 1" adjustable stainless bullet feet |
| Faucet holes | (2) sets, 8" on-center |
| Certifications | NSF & CSA-Sanitation listed |
| Ships | Knocked-down (KD) |
Built for Code Compliance
- NSF & CSA-Sanitation certification for food-service safety.
- 3 ½" drain openings accept NSF-listed lever waste assemblies.
- Coved 5/8" bowl corners and satin-polished welds meet health-department requirements for cleanability.
Care & Maintenance Tips
- Rinse and wipe dry after every shift to preserve the stainless passive film.
- Use non-chloride cleaners such as Bar Keepers Friend; avoid bleach and wire brushes.
- Polish periodically with John Boos Stainless Steel Cleaner to keep the #4 satin finish looking new.
Following these simple steps prevents pitting and corrosion, ensuring decades of reliable service.
