John Boos  |  Pro-Bowl  |  SKU: 4PB18-1D24L

John Boos 4PB18-1D24L Pro-Bowl Compartment Sinks

$3,310.76
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

John Boos Pro-Bowl 4-Compartment Sink w/ 24" Left Drainboard

Model 4PB18-1D24L | 16-Gauge Type 300 Stainless Steel

Engineered for demanding commercial kitchens, the John Boos Pro-Bowl series delivers rugged durability, food-safe hygiene and workflow-boosting convenience—all in one space-saving footprint.

Key Features
  • Four 18" W × 18" F/B × 12" D compartments for efficient wash-rinse-sanitize cycles plus a spare bay.
  • 24" left-side drainboard provides ample landing & air-dry space.
  • Heavy-duty 16 ga, Type 300 stainless steel with #4 satin polish resists corrosion & cleans fast.
  • Seamless TIG-welded construction; exposed welds polished to match surrounding surfaces.
  • 10" boxed backsplash with 45° top roll & 2" return protects walls from splash.
  • (2) splash-mount faucet hole sets, 8" on-center, 1" dia.—ready for pre-rinse or add-a-faucet units.
  • 3-1/2" die-stamped drain openings accept standard commercial basket strainers or lever wastes.
  • 1-5/8" O.D. stainless legs, adjustable front & side bracing, and bullet feet for rock-solid stability.
  • 5/8" radius coved bowl corners & bull-nosed outer edges enhance safety and cleanability.
  • Ships knock-down (KD) to reduce freight costs; assembles quickly on site.
  • NSF & CSA-Sanitation listed for full code compliance.
At-a-Glance Specifications
Overall size 100-3/16" W × 23-1/2" D × 44-1/16" H
Compartment size (4) 18" W × 18" F/B × 12" D
Drainboard 24" (left side)
Backsplash 10" H boxed, 45° top, 2" return
Faucet holes (2) sets, 8" centers, 1" dia.
Drain openings 3-1/2" die-stamped, one per bowl
Material / finish 16 ga Type 300 SS, #4 satin
Legs / bracing / feet 1-5/8" O.D. SS legs, adjustable 1-1/4" O.D. SS bracing, 1" SS bullet feet
Certifications NSF, CSA-Sanitation
Shipping Knock-Down (KD)
Perfect For
  • High-volume restaurants & commissaries
  • Institutional kitchens and cafeterias
  • Bakeries & food-processing facilities
  • Catering, banquet and event venues
Popular Accessories (sold separately)
  • 8" center deck or splash-mount faucets & pre-rinse sprayers
  • Lever waste drains & basket strainers
  • End splashes (left, right or both)
  • Single & double overshelves with optional pot racks

Need help configuring a complete warewashing station? Our equipment specialists are ready to assist.

Important: Faucet sets, drain assemblies and installation hardware are not included unless added to your order. Install per local plumbing codes.
Care & Maintenance
  • Clean daily with a mild, non-chloride detergent and a soft cloth or plastic scouring pad.
  • Rinse thoroughly and wipe dry—standing water or food acids may dull the finish.
  • Avoid steel wool and harsh chemicals that can damage the stainless protective film.
  • Restore shine with Bar Keepers Friend and John Boos Stainless Steel Cleaner as needed.

Following these practices will keep your Pro-Bowl sink looking new and performing at its best for years.

Features & Specs

Manufacturer

John Boos

Brand_name

Pro-Bowl

Certifications

NSF, CSA-Sanitation

Height

44.06in

Width

100.19in

Depth

23.5in

Shipping Weight

142.0lbs

Splash Height

10"

Compartment (front - back)

18"

Sink Depth (rim - drain)

12"

Top Gauge

16 gauge

Compartment Width (side - side)

18"

Drainboards

with left-hand drainboard

Base Construction

stainless steel

Base Type

legs with front & side crossrails

Overall Length

98" - 113"

Top Stainless Series

300 series

Specifications

Pro-Bowl Sink, 4-compartment, 100-3/16"W x 23-1/2"D x 44-1/16"H overall size, (4) 18"W x 18" front-to-back x 12" deep compartments, (1) 24" left drainboard, 10"H boxed backsplash with 45° top & 2" return, (2) sets of splash mount faucet holes with 8" centers, 3-1/2" die-stamped drain openings, 16/300 stainless steel construction, stainless steel legs, adjustable front & side bracing, adjustable bullet feet, NSF, CSA-Sanitation, KD
