John Boos

John Boos Pro-Bowl 4-Compartment Sink with 24-Inch Right Drainboard, 20-Inch Bowls, 12-Inch Deep

SKU: 44PB20-1D24R
$3,494.96
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

4-compartment Sinks Best Sellers Commercial Plumbing Supplies Commercial Sinks Compartment Sinks John Boos New Arrivals Restaurant Equipment Sinks & Handwashing Stations

John Boos Pro-Bowl 4-Compartment Sink with 24-Inch Right Drainboard, 20-Inch Bowls, 12-Inch Deep

108-3/16" x 25-1/2" x 44-1/16" Overall, 14-Gauge Type 300 Stainless Steel

A heavy-duty, floor-standing four-compartment sink built for high-volume wash stations, with a 24-inch right drainboard and durable stainless steel construction.

  • Four 20" x 20" x 12" deep compartments support multi-step dishwashing and prep workflows.
  • 24" right-hand drainboard adds dedicated landing and drying space.
  • 14-gauge Type 300 stainless steel construction is built for demanding commercial kitchens.
  • 10" boxed backsplash with a 45° top and 2" return helps contain splashes.
  • Two sets of 8" on-center faucet holes and 3-1/2" drain openings support installation and drainage.
  • Stainless steel legs, bracing, and adjustable bullet feet provide stable, level support.

Overall Dimensions:

108.19"W x 25.5"D x 44.06"H

Product Weight:

197.0 lb

Four Compartment Layout

Includes four separate 20" x 20" x 12" deep bowls for washing, rinsing, sanitizing, or prep tasks.

Right-Hand Drainboard

The 24" drainboard provides a convenient staging area on the right side of the sink.

Heavy-Duty Stainless Steel Construction

Built with 14-gauge Type 300 stainless steel and a stainless steel base for commercial durability.

Boxed Backsplash

The full-length 10" backsplash with a 45° top and 2" return helps reduce wall splash and cleanup.

Faucet Hole Layout

Features two sets of splash-mount faucet holes on 8" centers, plus 1" faucet holes in the backsplash.

Drainage-Friendly Bowls

Bowls are formed to drain to 3-1/2" die-stamped openings for efficient water removal.

Stable Stainless Steel Base

Stainless steel legs, front and side bracing, gussets, and adjustable bullet feet help keep the sink level and sturdy.

Knocked-Down Shipment

Ships KD for easier transport and on-site assembly.

Type Compartment Sink
Style Right Drainboard
Installation Type Floor Model
Compartments 4
Compartment Width 20 Inches
Compartment Depth 20 Inches
Sink Depth 12 Inches
Splash Height 10 Inches
Drain Opening Size 3-1/2 Inches
Faucet Hole Sets 2 Sets
Faucet Hole Spacing 8 Inches On Center
Material Stainless Steel
Finish #4 Polish, Satin Finish
Top Gauge 14 Gauge
Base Construction Stainless Steel
Base Type Legs with Front and Side Bracing
Selling Unit Each
Units Per Case 1
Shipping Width 109 Inches
Shipping Depth 26 Inches
Shipping Height 45 Inches
Shipping Weight 197 lb.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

This model includes a 24" right drainboard.
Each compartment measures 20" wide, 20" front-to-back, and 12" deep.
It is made from 14-gauge Type 300 stainless steel with a stainless steel base and #4 polish, satin finish.
It has a full-length 10" boxed backsplash with a 45° top and 2" return.
The sink includes two sets of splash-mount faucet holes on 8" centers, plus 1" faucet holes in the backsplash.
No. It ships knocked down (KD) for assembly.
