John Boos 44PB20-1D24L Pro-Bowl Compartment Sinks
Description
John Boos Pro-Bowl 44PB20-1D24L 4-Compartment Sink
108-3/16" W × 25-1/2" D × 44-1/16" H | 24" Left DrainboardBuilt for demanding commercial kitchens, the John Boos Pro-Bowl series pairs uncompromising durability with NSF-certified sanitation. This 4-compartment model streamlines your wash-rinse-sanitize workflow while the integrated drainboard keeps counters clutter-free.
Key Features
- (4) 20" W × 20" F/B × 12" D bowls—ideal for wash, rinse, sanitize & soak stations.
- 24" left-side drainboard speeds drying and staging.
- Heavy-duty 14 ga Type 300 stainless steel with #4 satin polish.
- 10" boxed backsplash with 45° top edge & 2" return protects surrounding walls.
- (2) sets of 8" on-center splash-mount faucet holes (1" dia.).
- 3-1/2" die-stamped drain openings for optimal flow.
- 1-5/8" O.D. stainless steel legs with adjustable front & side bracing.
- Stainless steel bullet feet adjust for a level, secure install.
- 5/8" radius interior corners & bull-nosed exterior edges for safe, easy cleaning.
- TIG-welded seams—exposed welds polished to match adjoining surfaces.
- Ships knocked-down (KD) to navigate narrow doorways and corridors.
- NSF & CSA-Sanitation listed for food-contact safety.
Technical Specifications
| Model | 44PB20-1D24L |
|---|---|
| Compartments | 4 |
| Bowl Size (W × F/B × D) | 20" × 20" × 12" |
| Drainboard | 24" (left) |
| Overall Dimensions | 108-3/16" W × 25-1/2" D × 44-1/16" H |
| Backsplash Height | 10" |
| Material | 14 ga / Type 300 stainless steel, #4 satin finish |
| Drain Opening | 3-1/2" die-stamped |
| Faucet Holes | (4) holes, 8" on-center (two sets) |
| Legs / Feet | Stainless steel legs with adjustable bullet feet |
| Ship Weight | Approx. 197 lb |
| Certifications | NSF, CSA-Sanitation |
Need a right-hand drainboard, deeper bowls, or add-on accessories such as pre-rinse units, lever wastes, or overshelves? Contact our team for a personalized quote.
