Titan Fire & Ice 102" Self-Contained Refrigerated Equipment Base with 6 Drawers

Full-Size, 6 Drawer, Self-Contained Refrigeration

The Titan Fire & Ice refrigerated equipment base provides expansive, convenient cold storage directly under your cooking equipment, enhancing efficiency and workflow in any commercial kitchen.

  • Spacious 102-inch refrigerated equipment base with a durable stainless steel exterior.
  • Features six self-closing drawers, accommodating up to ten 12" x 20" x 6" deep hotel pans.
  • Self-contained refrigeration system with a built-in condensate evaporator for hassle-free operation.
  • Heavy-duty construction with 100% polyurethane foam insulation for optimal temperature retention.
  • Equipped with 6-inch adjustable stainless steel legs for stability and easy cleaning.

Overall Dimensions:

102.0"W x 34.0"D x 25.0"H

Product Weight:

675.0 lb

Self-Contained Refrigeration

Integrated refrigeration system for easy installation without the need for remote condensers.

Generous Pan Capacity

Accommodates up to ten 12" x 20" x 6" deep hotel pans (pans sold separately) for ample cold storage.

Six Self-Closing Drawers

Includes two 14-3/8" wide and four 27-1/4" wide self-closing drawers, designed for smooth operation and durability.

Durable Stainless Steel Construction

Cabinet interiors, front face, and sides are constructed from stainless steel for longevity and hygiene in commercial environments.

High-Density Foam Insulation

Drawers and cabinet are 100% polyurethane "Shot-In-Place" foam insulated for superior temperature retention and energy efficiency.

Heavy-Duty Drawer System

Drawers feature flush mount pull handles, 14 gauge stainless steel tracks with 2" heavy-duty skate wheels, and are easily removable for cleaning.

Effective Sealing

Heavy-duty rubber drawer gaskets ensure a tight seal to maintain consistent internal temperatures.

Built-in Condensate Evaporator

Automatic condensate evaporation eliminates the need for an external drain connection, simplifying installation and maintenance.

Adjustable Stainless Steel Legs

Equipped with 6-inch adjustable stainless steel legs for stability on uneven floors and to facilitate cleaning underneath the unit.

Face Mounted Dial Thermometers

Provides easy-to-read temperature monitoring for precise control and food safety.

High-Density Breaker Strips

Specially designed high-density breaker strips are installed during the foaming process for enhanced thermal efficiency without visible fasteners.

Blower Coil Evaporator

Features a blower coil evaporator for efficient and even cooling throughout the cabinet.

Type Refrigerated Equipment Base
Style Self-Contained
Installation Type Floor Model (With Legs)
Pan Capacity 10 Full-Size Pans (12" x 20" x 6" deep)
Compartments 6
Controls Face Mounted Dial Thermometers
Material Stainless Steel
Interior Finish Stainless Steel
Exterior Finish Stainless Steel & Aluminum
Voltage 115 Volts
Amps 13.2 Amps
Watts 1.52 kW
Hertz 60 Hz
Phase 1-Phase
Refrigeration Type Self-Contained
Selling Unit Each
Units Per Case 1
Shipping Width 102 Inches
Shipping Depth 34 Inches
Shipping Height 25 Inches
Shipping Weight 675 lb.

Certifications & Compliance

Documents

PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

This unit features self-contained refrigeration, meaning the condenser and evaporator are integrated into the base, eliminating the need for a separate remote condensing unit.
The Titan Fire & Ice 102" refrigerated base is designed to accommodate up to ten 12" x 20" x 6" deep full-size hotel pans. Pans are sold separately.
This unit operates on 115 Volts, 60 Hz, 1-Phase electrical power and draws 13.2 Amps. It requires a single point electrical connection.
Yes, the drawers are designed to be easily removable for thorough cleaning. They also feature heavy-duty rubber gaskets and stainless steel construction for hygiene.
No, the Titan Fire & Ice refrigerated base is equipped with a built-in condensate evaporator, which automatically disposes of condensation, eliminating the need for an external drain.
