Jade Range (Middleby)

Titan JMRH-4-A 24-Inch 4-Burner Modular Heavy Duty Gas Open Burner Range

SKU: JMRH-4-A
$6,767.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Gas Ranges Commercial Ranges Gas Ranges Jade Range (Middleby) New Arrivals Ranges Restaurant Equipment

Titan JMRH-4-A 24-Inch 4-Burner Modular Heavy Duty Gas Open Burner Range

Modular, 4 Open Burners, Stainless Steel Exterior

Experience superior cooking performance and flexibility with the Titan JMRH-4-A modular heavy-duty gas open burner range, designed for rigorous commercial kitchen demands.

  • Equipped with (4) 35,000 BTU/hr cast iron open burners for powerful and consistent heat.
  • Durable 14 gauge all-welded body construction with a stainless steel front, sides, and stub back ensures longevity.
  • Features individual lift-off steel top grates for easy cleaning and maintenance.
  • Includes a convenient 6-inch stainless steel plate shelf, perfect for plating and holding.
  • Modular design allows for flexible kitchen configurations and integration with other Titan equipment.
  • Heavy-duty construction is built to withstand the demands of a busy commercial environment.

Overall Dimensions:

24.0"W x 36.25"D x 36.5"H

Product Weight:

225.0 lb

Heavy Duty Construction

Built with a 14 gauge all-welded body and stainless steel front, sides, and stub back for exceptional durability and commercial use.

High-Performance Open Burners

Features four powerful 35,000 BTU/hr cast iron open burners, each with individual lift-off steel top grates and a stainless steel pilot, offering precise and intense heat for various cooking tasks.

Stainless Steel Gas Tubing

Ensures reliability and longevity with stainless steel gas tubing used throughout the unit.

Integrated Plate Shelf

Comes standard with a 6-inch stainless steel plate shelf, providing convenient space for staging dishes or storing frequently used items.

Infinite Controls

Each open burner is controlled by an infinite gas valve, allowing for precise temperature adjustment.

Modular Design

Designed in 12-inch sections for modularity, allowing for flexible kitchen layouts and expansion.

Type Open Burner Range
Style Modular
Installation Type Floor Model (With Legs)
Compartments 1
Controls Infinite Gas Valves
Pan Capacity 4 Open Burners
BTU 140,000 BTU
Gas Type Natural Gas or Propane
Gas Connection Size 3/4 Inch
Gas Inlet Pressure Natural Gas: 5 Inches W.C. Minimum; Propane Gas: 10 Inches W.C. Minimum; 14 Inches W.C. Maximum
Material Stainless Steel
Finish Stainless Steel
Selling Unit Each
Units Per Case 1
Shipping Width 24 Inches
Shipping Depth 37 Inches
Shipping Height 37 Inches
Shipping Weight 225 lb.
Country of Origin USA

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The JMRH-4-A range can be configured for either Natural Gas or Propane. Please specify the required gas type when ordering.
The Titan JMRH-4-A heavy-duty gas open burner range has a total BTU output of 140,000 BTU, with each of its four burners rated at 35,000 BTU/hr.
Yes, this unit must be connected with the 3/4 inch gas appliance regulator that is supplied loose and must be installed for proper operation.
For Natural Gas, a minimum of 5 inches W.C. operating pressure is required. For Propane Gas, a minimum of 10 inches W.C. operating pressure is required. The maximum operating pressure is 14 inches W.C. for both gas types.
Yes, but you must specify the altitude when ordering if it is above 2,000 ft. to ensure proper configuration.
