Jade Range (Middleby)

Titan JCB-30 30-Inch Gas Chicken Broiler with 5 Burners

SKU: JCB-30
$11,754.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?

Titan JCB-30 30-Inch Gas Chicken Broiler with 5 Burners

30-Inch Width, Natural Gas or Propane, Floor Model, 75,000 BTU

The Titan JCB-30 Gas Chicken Broiler offers robust construction and precise individual burner control for consistently perfect broiling in demanding commercial kitchens.

  • Constructed from durable 14 gauge all stainless steel for long-lasting performance.
  • Features 5 independently controlled burners, providing one burner for every 6 inches of broiler width.
  • Removable stainless steel superstructure offers 4 levels of broiling and additional cooking space.
  • Equipped with an extra-large, self-draining gutter for efficient grease management.
  • Specially designed flame control grates ensure even heat distribution and precise results.
  • Includes a stainless steel front, sides, plate shelf, bottom shelf, and sturdy legs for a complete floor model setup.

Overall Dimensions:

30.0"W x 30.5"D x 42.0"H

Product Weight:

380.0 lb

Heavy-Duty Construction

Built with a 14 gauge all stainless steel welded body and 12 gauge all welded firebox construction for exceptional durability and longevity in a commercial setting.

Independent Burner Control

Features 5 burners, each with precision individual control, allowing for versatile cooking zones and optimal temperature management.

Multi-Level Broiling

A removable stainless steel superstructure provides 4 levels of broiling and an additional 4 inches of cooking space at the rear, maximizing cooking capacity.

Efficient Grease Management

An extra-large, self-draining gutter effectively collects grease and drippings, simplifying cleaning and maintenance.

Optimized Cooking Grates

Specially designed flame control grates ensure even heat distribution and consistent broiling performance.

Integrated Gas Regulator

Comes with a 3/4 inch gas regulator that must be connected for proper operation.

Full Stainless Steel Exterior

The unit boasts a stainless steel front, sides, and a convenient plate shelf, complemented by stainless steel legs and a bottom shelf for storage and stability.

Type Chicken Broiler
Style Broiler
Installation Type Floor Model (With Stand)
Burners 5
Cooking Levels 4
BTU 75,000 BTU
Gas Connection Size 3/4 Inch NPT
Gas Inlet Pressure (Natural Gas Minimum) 5 Inches W.C.
Gas Inlet Pressure (Propane Gas Minimum) 10 Inches W.C.
Gas Inlet Pressure (Maximum) 14 Inches W.C.
Material 14 Gauge Stainless Steel
Exterior Finish Stainless Steel Front and Sides
Controls Individual Burner Controls
Selling Unit Each
Units Per Case 1
Shipping Width 30 Inches
Shipping Depth 31 Inches
Shipping Height 42 Inches
Shipping Weight 380 lb.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

Manufacturer reserves the right to change materials and specifications without notice.

Frequently Asked Questions

The JCB-30 can operate on either Natural Gas or Propane. The specific gas type must be specified when placing an order.
The JCB-30 features 5 burners, each of which can be controlled independently for precise cooking.
For Natural Gas, a minimum of 5 inches W.C. operating pressure is required. For Propane Gas, a minimum of 10 inches W.C. operating pressure is required. The maximum allowed pressure is 14 inches W.C. for both.
Yes, a 3/4 inch gas appliance regulator is supplied with the unit and must be connected for safe and proper operation.
Yes, the stainless steel superstructure is designed to be removable, making it easy to clean and maintain hygiene.
Yes, if the installation location is above 2,000 feet, the altitude must be specified when ordering the unit.
