Jade Range (Middleby)

Titan JCB-24 24-Inch Gas Chicken Broiler with 4 Burners

SKU: JCB-24
$10,321.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Charbroilers & Grills Gas Charbroilers Jade Range (Middleby) Mexican Restaurant Cooking Equipment Mexican Restaurant Supplies New Arrivals

Titan JCB-24 24-Inch Gas Chicken Broiler with 4 Burners

Floor Model, Natural Gas or Propane, Standard Depth

Engineered for high-volume commercial kitchens, the Titan JCB-24 chicken broiler delivers exceptional broiling performance and durability in a compact 24-inch footprint.

  • Constructed from durable 14 gauge all stainless steel with a welded body for longevity.
  • Features 4 independently controlled burners, providing precise heat management.
  • Offers 4 levels of broiling and an additional 4 inches of cooking space at the rear for versatility.
  • Equipped with an extra-large, self-draining gutter for simplified cleaning and grease management.
  • Operates on 60,000 BTU, available for Natural Gas or Propane operation.
  • Includes stainless steel front, sides, plate shelf, bottom shelf, and legs for a complete floor model setup.

Overall Dimensions:

24.0"W x 30.5"D x 42.0"H

Product Weight:

340.0 lb

14 Gauge All Stainless Steel Welded Body Construction

Ensures exceptional strength and durability, designed to withstand the rigors of a busy commercial kitchen environment.

Precision Individual Burner Control

Allows for independent heat adjustment for each of the four burners, providing precise temperature control across the cooking surface for varied menu items.

Stainless Steel Superstructure

Removable for easy cleaning and offers 4 distinct levels of broiling, along with an additional 4 inches of cooking space at the rear for enhanced capacity and flexibility.

Extra-Large, Self-Draining Gutter

Efficiently collects grease and debris, simplifying the cleaning process and maintaining a cleaner work area.

Specially Designed Flame Control Grates

Optimizes heat distribution and prevents flare-ups, ensuring consistent cooking results and enhanced product quality.

12 Gauge All Welded Firebox Construction

Provides a robust and durable cooking chamber, contributing to the broiler's long lifespan and consistent performance.

Stainless Steel Exterior and Plate Shelf

Features a sleek and professional stainless steel front, sides, and a convenient plate shelf for plating or holding food.

Stainless Steel Legs and Bottom Shelf

Provides stable support and includes a practical bottom shelf for additional storage of utensils or ingredients.

Type Chicken Broiler
Style Floor Model (With Open Stand)
Installation Type Floor Model
BTU 60,000
Compartments 1
Burners 4
Gas Type Natural Gas or Propane
Gas Connection Size 3/4 Inches NPT
Gas Inlet Pressure (Natural Gas) 5 Inches W.C. (minimum)
Gas Inlet Pressure (Propane Gas) 10 Inches W.C. (minimum)
Gas Inlet Pressure (Maximum) 14 Inches W.C.
Material Stainless Steel
Interior Finish 12 Gauge All Welded Firebox Construction
Exterior Finish Stainless Steel Front & Sides
Cooking Levels 4
Width 24 Inches
Depth 30.5 Inches
Height 42 Inches
Weight 340 lb.
Shipping Width 24 Inches
Shipping Depth 31 Inches
Shipping Height 42 Inches
Shipping Weight 340 lb.
Selling Unit Each
Units Per Case 1
Country of Origin USA

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The Titan JCB-24 broiler can be configured to operate on either Natural Gas or Propane. The specific gas type must be specified when placing an order.
For Natural Gas, a minimum operating pressure of 5 inches W.C. is required. For Propane Gas, a minimum of 10 inches W.C. is required. The maximum operating pressure for both types is 14 inches W.C.
The JCB-24 chicken broiler features a stainless steel superstructure that provides 4 distinct levels of broiling, offering versatile cooking options.
Yes, the stainless steel superstructure of the JCB-24 is designed to be removable, facilitating easier and more thorough cleaning.
The Titan JCB-24 chicken broiler has a total heat output of 60,000 BTU, distributed across its four independently controlled burners.
Yes, the unit must be connected with the gas appliance regulator supplied by Jade Range, and you must specify the type of gas when ordering. If installing above 2,000 feet, the altitude should also be specified.
