Insinger Power Side Loader
Stainless-Steel 90° Rack Conveyor AccessoryMaximize dishroom throughput and reclaim valuable floor space with the Insinger Power Side Loader. Designed for Insinger rack conveyor warewashers, this independent, motor-driven module lets operators feed racks at a right angle—eliminating long, curved rollers and making tight layouts easy.
Key Benefits
- Space-saving 90° loading—perfect for corners or around columns.
- Handles up to 330 racks per hour; accepts 22" trays in an open-end rack.
- Works left-to-right or right-to-left and pairs with any Insinger rack conveyor machine.
- Three powered rollers move racks at 10 surface ft/min for smooth, consistent loading.
- Dedicated ¹∕₃ HP motor keeps dishwasher drive system stress-free.
- All-welded 16-gauge type 304 stainless steel pan with 10" backsplash & 1½" rolled rim.
- Stainless steel guards shield moving parts for safer operation and easy cleaning.
Technical Specifications
| Rack Capacity* | Up to 330 racks/hr (20" × 20") |
|---|---|
| Tray Capacity | 22" trays in open-end rack |
| Roller Count / Speed | 3 powered rollers @ 10 ft/min |
| Drive Motor | ¹∕₃ HP, internally fan-cooled, ball-bearing |
| Construction | 16 ga 304 stainless steel; all-welded |
| Backsplash / Rim | 10" backsplash, 1½" rolled rim |
| Orientation | Field convertible – left-to-right or right-to-left |
| Compatibility | All Insinger rack conveyor models |
Electrical – Current Draw
| Voltage / Phase / Hz | Amps (Loader) |
|---|---|
| 208 V / 3 ph / 60 Hz | 1.7 A |
| 220 V / 1 ph / 60 Hz | 3.4 A |
| 240 V / 3 ph / 60 Hz | 1.5 A |
| 380 V / 3 ph / 50 Hz | 0.9 A |
| 480 V / 3 ph / 60 Hz | 0.8 A |
*Actual throughput is limited by the connected dishwasher’s rated capacity.
Warranty
Backed by Insinger’s SureFire limited warranty: one (1) year parts & labor when installed and operated per the supplied manual.
