Infrico USA IDC-VML12 Refrigerated Fish Display Case, 52-3/8"W, Curved Glass, Stainless Steel Exterior

SKU: IDC-VML12
$5,949.71
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Infrico USA IDC-VML12 is a refrigerated fish display case with 4.06 cu. ft. of capacity, curved tempered front glass, and a 25 lb. ice load capacity.

It features 300 series stainless steel interior and exterior construction, LED lighting, rear sliding windows, an internal drain, and a stainless steel rear worktop. The self-contained refrigeration system uses a static evaporator with gravity coil and cold plate refrigeration on the bottom.

  • Temperature control: Digital controller with a 30°F to 34°F temperature range.
  • Electrical: 115 V, single-phase, 60 Hz connection with a NEMA 5-20P plug.
  • Certifications: cETLus and ETL-Sanitation.

Overall Dimensions:

52.38"W x 35.44"D x 52.56"H

Product Weight:

386.0 lb

Curved tempered front glass

The front glass is curved tempered glass with a lift-up system.

Stainless steel construction

The interior and exterior use 300 series stainless steel, with an AISI 304 stainless steel rear worktop.

Self-contained refrigeration

The bottom-mounted refrigeration system uses a static evaporator with gravity coil and cold plate.

Digital temperature control

A digital controller regulates temperature and defrost; the stated temperature range is 30°F to 34°F.

LED lighting

Interior LED lighting is included.

Rear sliding windows

Rear sliding windows provide access to the display case.

Internal drain

An internal drain supports evacuation of cleaning liquids.

Ice load capacity

The case supports an ice load capacity of 25 lb.

Related Searches

Best Sellers Display Refrigeration Food Displays & Merchandisers Infrico USA New Arrivals Refrigerated Deli, Bakery & Sushi Cases Refrigerated Display Case Equipment Refrigerated Display Cases Refrigeration & Ice Restaurant Equipment
Product type Refrigerated fish display case
Capacity 4.06 cu. ft.
Refrigeration Self-contained refrigeration
Refrigeration system Static evaporator with gravity coil and cold plate, on the bottom
Temperature range 30°F to 34°F
Ice load capacity 25 lb.
Front glass Curved tempered glass with lift-up system
Access Rear sliding windows
Interior and exterior material 300 series stainless steel
Worktop material AISI 304 stainless steel
Lighting LED
Controller Digital controller
Drain Internal drain
Defrost Manual defrost
Refrigerant R134a
Refrigeration capacity 1,584 Btu/h at 14°F / 464 W at -10°C
Electrical connection 115 V / 1 ph / 60 Hz
Plug NEMA 5-20P
Compressor horsepower 1/3 HP
Insulation CFC-free polyurethane insulation

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Warranty & Protection

5-year warranty on parts and labor, plus an additional 7-year warranty on the compressor part only.

Documents

PDF Cutsheet PDF Download PDF Warranty announcement 2023 PDF Download PDF Freight program PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The IDC-VML12 has a refrigerated display capacity of 4.06 cu. ft.
The product measures 52.38 in. wide, 35.44 in. deep, and 52.56 in. high, with a listed weight of 386 lb.
It uses self-contained refrigeration with a static evaporator, gravity coil, and cold plate positioned on the bottom.
The case requires 115 V, single-phase, 60 Hz power and includes a NEMA 5-20P plug.
Yes. The IDC-VML12 has a 25 lb. ice load capacity.
It has a curved tempered front glass lift-up system and rear sliding windows.
The listed certifications are cETLus and ETL-Sanitation.
For products shipped on or after February 1, 2024, the warranty sheet states 5 years on parts and labor, plus an additional 7-year compressor warranty covering the part only.
