Imperial (Middleby) PSH1060 Pro Series Hot Plates
Description
Imperial Pro Series 60" Countertop Gas Hot Plate
Model PSH1060 • 10 Open Burners • 320,000 BTUBuilt for the relentless pace of high-volume kitchens, the Imperial Pro Series PSH1060 delivers uncompromising power, rugged durability, and the flexible cooking surface chefs rely on every day. Ten 32,000 BTU open burners sit beneath newly engineered cast-iron grates, giving you rapid heat recovery and precise flame control—perfect for everything from searing steaks to simmering sauces.
Why Choose the PSH1060
- Massive Output: 320,000 BTU total (32,000 BTU per burner) keeps up with peak-hour demand.
- All-Stainless Exterior: Heavier-gauge 304 stainless steel front, sides, stub back, landing ledge & cabinet withstand years of commercial abuse.
- Cast-Iron Top Grates: New bowl design centers pots and maximizes heat transfer.
- Seamless Construction: 100 % welded & polished seams and a fully welded stainless crumb tray for effortless cleanup.
- Operator-Friendly Controls: Durable die-cast metal knobs with all-brass components for smooth, accurate adjustments.
- Low-Profile Design: Fits comfortably on worktops or refrigerator bases while providing a convenient landing ledge for plating.
- Ready to Install: Includes 4" stainless steel legs, 3/4" NPT rear gas connection, shut-off valve, and pressure regulator.
- Certified & Protected: CSA Star & CSA Flame approved; backed by a 1-year parts & labor warranty.
Technical Specifications
| Exterior width | 60 in / 1524 mm |
|---|---|
| Exterior depth | 29 3⁄4 in / 756 mm |
| Exterior height (to grate) | 11 1⁄4 in / 286 mm |
| Number of open burners | 10 |
| BTU per burner | 32,000 |
| Total BTU input | 320,000 |
| Gas connection | 3/4" NPT (rear) |
| Ship weight | 375 lb / 170 kg (crated) |
| Certifications | CSA Star, CSA Flame |
| Warranty | 1-year parts & labor |
Popular Options & Accessories
- Stainless steel equipment stand (with optional 6" casters)
- Stainless center shelf for open-base stands
- 6" heavy-duty adjustable legs (replace standard 4")
- Quick-disconnect & flexible gas hose kits – 3/4" or 1-1/4" NPT
Need a different size? The Pro Series hot plate line is also available in 24", 36", and 48" widths.
All gas equipment should be installed by a licensed professional in accordance with local codes.
