Imperial (Middleby) IR-G60 Pro Series Gas Ranges
Description
Imperial Pro Series 60" Gas Griddle Range with Double Standard Ovens
Model IR-G60 | 170,000 BTU (50 kW)Built for high-volume kitchens, the Imperial Pro Series IR-G60 combines a full-width 60" griddle with two spacious Chef-Depth ovens—delivering the power, durability, and ease of cleaning demanded by busy diners, cafés, and institutions.
Why It Belongs on Your Line
- All-griddle top – 60" (1524 mm) cooking surface, 3/4" (19 mm) polished steel plate, and 21" working depth.
- Even heat distribution – individual 20,000 BTU burners every 12" with integrated steel heat deflectors for consistent temps across the plate.
- Low-maintenance grease management – 3" (76 mm) wide trough plus a large removable grease can and full-width crumb tray.
- Dual Chef-Depth ovens (26-1/2" W × 26" D × 14" H each) handle 18" × 26" sheet pans left-to-right and front-to-back.
- 35,000 BTU linear burners and exclusive heat deflectors ensure even baking and roasting.
- Rugged all-stainless exterior—front, sides, backguard, high-shelf, 3-1/2" landing ledge, and kick plate.
- 6" heavy-duty legs with adjustable feet; optional casters available.
- Manual controls for straightforward, reliable operation.
Built to Last
- Porcelainized oven interior, deck, and door liner for fast wipe-downs.
- Lift-off burners and two-piece cast-iron top grate system simplify daily cleaning.
- Welded and polished seams resist corrosion in harsh kitchen environments.
- Durable cast-aluminum control knobs stand up to constant use and abuse.
Compliance & Certifications
- NSF Listed – food-service sanitation approved
- CSA Flame & CSA Star
- CE Marked
Technical Specs
| Overall Width | 60" (1524 mm) |
|---|---|
| Overall Depth | 31-1/2" (800 mm) |
| Overall Height (to top of shelf) | 56-1/2" (1435 mm) |
| Total Gas Input | 170,000 BTU / 50 kW |
| Gas Connection | 3/4" NPT rear manifold |
| Manifold Pressure | Natural 5.0" W.C. | LP 10.0" W.C. |
| Oven Capacity (each) | 26-1/2" W × 26" D × 14" H (Chef-Depth) |
| Oven Heat | 35,000 BTU linear burner per oven |
| Griddle Plate | 60" W × 21" D × 3/4" thick polished steel |
| Grease Trough | 3" width, stainless, front-mounted |
| Ship Weight | 1,115 lb (505 kg) |
| Warranty | 1-year parts & labor (factory authorized service) |
Need a quick ship? Ask about factory-installed options such as thermostatic griddle controls, grooved plates, or casters to tailor the IR-G60 to your exact workflow.
