Imperial IR-4-G36T-E Pro Series 60" Electric Restaurant Range with (4) Elements and 36" Thermostatic Griddle

Full-Size, Electric, (4) Round Elements, (1) 36" Griddle, (2) Standard Ovens

Experience robust cooking versatility and reliable performance with the Imperial IR-4-G36T-E electric restaurant range, designed for demanding commercial kitchens.

  • Equipped with four 9" sealed round plate elements for consistent, easy-to-clean cooking surfaces.
  • Features a 36" wide, 3/4" thick steel griddle with precise thermostatic controls for even heating.
  • Includes two standard ovens, each with a 5.3 kW element and a heavy-duty thermostat, accommodating full-size sheet pans.
  • Durable stainless steel construction on the front, sides, backguard, shelf, landing ledge, and kick plate ensures longevity.
  • Porcelainized oven interiors and removable grease can simplify cleaning and maintenance.
  • Comes with 6" heavy-duty legs and adjustable feet for stable floor mounting.
  • Offers a versatile electrical configuration to suit various kitchen setups (available in 208V, 240V, 480V; 1-phase or 3-phase).

Overall Dimensions:

60.0"W x 31.25"D x 56.5"H

Product Weight:

1085.0 lb

Sealed Round Plate Elements

Four 9" (229 mm) sealed round plate elements provide a solid, flat surface for fast, even heating and easy cleanup, preventing spills from entering the unit. Each element features infinite heat controls for maximum cooking flexibility.

Thermostatic Griddle Top

A thick, highly polished 3/4" (19 mm) steel griddle plate with a 21" (533 mm) depth and thermostat controls ensures even heating across the griddle section. Includes a 4" (102 mm) wide grease trough and a large, removable grease can for convenient cleaning.

Standard Ovens

Two high-performance standard ovens, each with a 5.3 kW element, deliver even heating. A unique baffle above the element distributes heat, while a splatter screen protects it from spills. Oven interior dimensions are 26-1/2" w x 26" d x 14" h, accommodating standard 18" x 26" sheet pans front-to-back and side-by-side. Temperature range from 150°F to 500°F.

Durable Construction

Constructed with a stainless steel front, sides, backguard, shelf, landing ledge, and kick plate, featuring welded and polished seams for enhanced durability and a professional appearance. Includes a large 5" (127 mm) stainless steel landing ledge for plating.

Easy to Clean Interior

Oven interiors feature porcelainized sides, rear, deck, and door lining for easy cleaning. The stamped inner door liner also provides extra strength and optimizes heat retention.

Heavy-Duty Legs

Equipped with 6" (152 mm) heavy-duty legs with adjustable feet, ensuring stability and proper clearance for cleaning.

Cast Aluminum Controls

Control knobs are made of durable cast aluminum and feature a Valox™ heat protection grip, ensuring safe and comfortable operation.

Type Restaurant Range
Style Floor Model (With Legs)
Installation Type Floor Model (With Legs)
Top (4) 9" Round Elements, (1) 36" Thermostatic Griddle
Ovens 2 Standard Ovens
Controls Infinite Heat Controls (Elements), Thermostatic (Griddle), Heavy Duty Thermostat (Ovens)
Griddle Plate Thickness 0.75 Inches
Griddle Depth 21 Inches
Pan Capacity One (18" x 26") Full-Size Sheet Pan Per Oven
Compartments 2
Temperature Range 150°F to 500°F
Exterior Finish Stainless Steel Front & Sides
Interior Finish Porcelain
Legs 6 Inches
Electrical Connection Hardwired
Total Watts 25.3 kW
Voltage 208 Volts
Phase 1-Phase
Amps 64 Amps
Hertz 60 Hz
Shipping Width 60 Inches
Shipping Depth 32 Inches
Shipping Height 57 Inches
Shipping Weight 1085 lb.
Country of Origin USA
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Warranty & Protection

1-Year Parts and Labor Warranty

Documents

PDF Cutsheet PDF Download PDF Parts manual PDF Download PDF Middleby financial flyer PDF Download PDF Training video PDF Download PDF Owner's manual PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The IR-4-G36T-E features four 9" sealed round plate electric elements and a 36" wide thermostatic griddle with a 3/4" thick polished steel plate.
Each of the two standard ovens has an interior of 26-1/2" wide x 26" deep x 14" high, designed to accommodate one standard 18" x 26" full-size sheet pan, front-to-back or side-by-side. The ovens also include one chrome rack each.
The IR-4-G36T-E requires 25.3 kW and is available in various electrical configurations including 208V (1-phase or 3-phase), 240V (1-phase or 3-phase), and 480V (3-phase). Specific amperage will vary based on the chosen voltage and phase.
Yes, the griddle features a 4" wide grease trough and a large, removable grease can, making cleanup simple and efficient.
This Imperial restaurant range comes with a one-year parts and labor warranty to the original purchaser, covering defects in material and workmanship under normal use and service, provided the equipment is less than two years old from the date of manufacture and purchased in the United States or Canada.
