Imperial (Middleby) IR-4-G36-XB Pro Series Gas Ranges
Description
Imperial Pro Series 60" Gas Restaurant Range
Model IR-4-G36-XB | 4 Burners • 36" Griddle • Standard Oven & Cabinet BaseGive your kitchen the fire-power and flexibility of a full cookline in one rugged unit. The Pro Series IR-4-G36-XB combines high-performance open burners, an even-heating 36" griddle and a chef-depth oven—wrapped in easy-to-clean stainless steel—to tackle any menu rush.
Why You’ll Love It
- 223,000 BTU total output delivers rapid recovery when the tickets stack up.
- Four 32,000 BTU PyroCentric™ open burners with 7,000 BTU low-simmer for delicate sauces.
- 36" x 21" griddle (¾" polished steel) heats evenly with 20,000 BTU per 12" section.
- Chef-depth standard oven (35,000 BTU) fits full-size 18" x 26" sheet pans left-to-right or front-to-back.
- Open cabinet base and bottom shelf keep hotel pans, sheet pans or smallwares within reach.
- All-stainless exterior, 3.5" landing ledge and full-width crumb tray speed daily clean-up.
- NSF, CE, CSA Flame & Star listed for safety and sanitation world-wide.
Cooking Performance
- Open burners: Cast-iron, anti-clog design lifts off in seconds—no gaskets or screws.
- Cast-iron grates: 12" x 12" front / 12" x 13" rear let stock pots slide easily over the landing ledge.
- Griddle: 3" wide grease trough plus removable grease can stop flare-ups and cut clean-up time.
- Oven: Porcelainized interior, exclusive heat deflector for even temps, one chrome rack included.
Built to Last
- Welded stainless steel front, sides, backguard, high-shelf, landing ledge and kick plate.
- Durable cast-aluminum control knobs stand up to constant use.
- 6" heavy-duty legs with adjustable feet (casters optional).
Specifications
| Model | IR-4-G36-XB |
|---|---|
| Overall width | 60" / 1524 mm |
| Depth (incl. landing ledge) | 31-1/2" / 800 mm |
| Height (to cook surface / with backguard) | 36" / 56-1/2" |
| Total BTU | 223,000 BTU (65 kW) |
| Open burners | 4 × 32,000 BTU PyroCentric™ |
| Griddle size | 36" W × 21" D, ¾" steel plate |
| Oven type / BTU | Standard, 35,000 BTU |
| Oven interior (W × D × H) | 26-1/2" × 26" × 14" (673 × 660 × 356 mm) |
| Racks supplied | 1 chrome rack (3 positions) |
| Base | Open cabinet with bottom shelf |
| Gas connection | 3/4" NPT rear manifold |
| Manifold pressure | 5" W.C. Natural | 10" W.C. LP |
| Certifications | NSF, CE, CSA Flame & CSA Star |
| Warranty | 1-year parts & labor (see details below) |
Imperial warrants this range to the original purchaser for one year on parts and labor when installed, operated and maintained in accordance with provided instructions.
