Imperial (Middleby) IR-4-G24T-E Pro Series Electric Ranges
Description
Imperial Pro Series 48" Electric Restaurant Range
4 Sealed Round Elements • 24" Thermostatic Griddle • Double 20" Space-Saver OvensBring unsurpassed versatility, power and durability to your cookline with the Imperial Pro Series 48" electric range. Four high-output round elements, a full-size thermostatic griddle and two independent space-saver ovens let you sear, sauté, bake and roast in one compact footprint—all wrapped in heavy-gauge stainless steel built for the daily grind of a busy kitchen.
Why You’ll Love It
- High-output cooktop: Four 9" (2 kW) sealed round plate elements deliver fast, even heat and wipe clean in seconds.
- Thermostatic griddle: 24" W x 21" D, 3/4" polished steel plate with a 150 – 500 °F thermostat for precision grilling.
- Double space-saver ovens: Each 20" W cavity holds a full 18" x 26" sheet pan front-to-back and is powered by a 5.3 kW element.
- Infinite heat controls: Separate dial for every element plus heavy-duty oven thermostats put total control at your fingertips.
- Kitchen-tough build: Stainless steel front, sides, backguard, 5" landing ledge & kick plate with welded seams.
- Speedy cleanup: 4" grease trough, removable extra-capacity grease can, porcelainized oven interior and splatter screens.
- Operator-friendly details: Stay-cool cast-aluminum knobs, 6" adjustable legs (casters optional) and chromed oven racks.
- Certified safe & sanitary: cETLus, ETL-Sanitation and CE listed; backed by a 1-year parts & labor warranty.
Technical Specifications
| Model | IR-4-G24T-E (Pro Series) |
|---|---|
| Overall width | 48" (1219 mm) |
| Depth | 31-1/4" (794 mm) |
| Height | 36" (914 mm) to cooktop / 56-1/2" (1435 mm) with backguard |
| Cooktop | (4) 9" sealed round plate elements, 2 kW each |
| Griddle | 24" W x 21" D, 3/4" thick polished steel, thermostatic 150-500 °F |
| Ovens | (2) 20" W x 26" D x 14" H cavities, 5.3 kW each, (1) chrome rack per oven |
| Landing ledge | 5" stainless steel |
| Total load | 24.6 – 26.6 kW (voltage dependent) |
| Voltage / phase | 208 V or 240 V 1-ph (64 / 56 A) - or - 208 V or 240 V 3-ph (55 / 31 A) 480 V 3-ph (17 A) optional |
| Grease management | 4" trough & removable can |
| Construction | Stainless steel front, sides, backguard, kick plate & landing ledge |
| Legs | 6" heavy-duty, adjustable (casters optional) |
| Certifications | cETLus, ETL-Sanitation, CE |
| Warranty | 1-year parts & labor |
| Shipping weight | ≈ 810 lb (367 kg) |
Popular Options & Accessories
- 6" or 11" stainless stub back (replaces full backguard)
- Reinforcement channels for cheesemelter / salamander
- Additional chrome oven racks
- Chrome-plated griddle surface
- 6" locking casters
- 480 V, 3-phase wiring
Imperial reserves the right to change specifications without notice. Always verify electrical requirements and local code compliance before ordering.
