Imperial (Middleby)

Imperial Pro Series 24-Inch Electric Range with 4 Round Plate Elements, Solid Top, and Open Cabinet Base

SKU: IR-4-E-XB
$6,381.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Bar Trays Best Sellers Electric Ranges Imperial (Middleby) New Arrivals Ranges Smallwares Trays & Accessories

Imperial Pro Series 24-Inch Electric Range with 4 Round Plate Elements, Solid Top, and Open Cabinet Base

Built for high-volume kitchens, this compact 24-inch electric range combines four round plate elements, infinite heat control, and durable stainless steel construction in a space-saving open-cabinet design.

  • Four 9-inch round plate elements maximize pan contact and deliver even heating.
  • Solid-top construction helps keep spills out of the unit for easier cleanup.
  • Infinite heat controls provide flexible temperature adjustment for a wide range of cooking tasks.
  • Open cabinet base with bottom shelf adds convenient under-range storage.
  • Stainless steel front, sides, backguard, landing ledge, and kick plate are built for durability.
  • 6-inch heavy-duty legs with adjustable feet help stabilize and level the range.
  • One-year parts and labor warranty provides added peace of mind.

Overall Dimensions:

24.0"W x 31.25"D x 56.5"H

Product Weight:

405.0 lb

Four 9-Inch Round Plate Elements

Round plate cooking surfaces provide maximum pan contact and a flat, easy-to-clean surface.

Solid Top Design

The solid top helps prevent spills from entering the unit and simplifies daily cleanup.

Infinite Heat Controls

Allows precise, flexible heat adjustment for different cooking applications.

Open Cabinet Base with Bottom Shelf

Offers accessible under-range storage and a practical open base design.

Stainless Steel Exterior

Stainless steel front, sides, backguard, landing ledge, and kick plate help the range stand up to heavy use.

Heavy-Duty Adjustable Legs

6-inch legs with adjustable feet support stable installation and leveling.

Full-Width Removable Crumb Tray

A removable crumb tray makes routine cleaning faster and easier.

Type Electric Range
Style Open Cabinet
Installation Type Floor Model
Controls Infinite Heat
Material Stainless Steel
Finish Stainless Steel
Voltage 208/240/480 Volts
Phase 3-Phase
Watts 10.4 kW
Amps 44/38/19 Amps
Country of Origin USA
Selling Unit Each
Units Per Case 1
Shipping Width 24 Inches
Shipping Depth 32 Inches
Shipping Height 57 Inches
Shipping Weight 405 Pounds

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Warranty & Protection

1-year parts and labor

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Parts manual PDF Download PDF Training video PDF Download PDF Middleby financial flyer PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

No. The IR-4-E-XB is configured with an open cabinet base and bottom shelf rather than a standard oven.
It has four 9-inch diameter round plate elements.
It uses infinite heat controls for flexible temperature adjustment.
The model is rated at 10.4 kW, and the documentation lists 208V, 240V, and 480V three-phase electrical requirements. Imperial also notes additional single-phase options by request.
The range includes a one-year parts and labor warranty.
It is for use on non-combustible floors only. Provide 0 inches clearance from non-combustible surfaces and 6 inches from combustible surfaces.
