Imperial (Middleby) IR-36-LB-C Pro Series Specialty Ovens
Description
Imperial Pro Series Range-Match Gas Convection Oven
Model IR-36-LB-C • 30,000 BTU • Single DeckBuilt to slide neatly beneath a 36" Imperial Pro Series range—or operate as a stand-alone workhorse—this compact convection oven delivers the production capacity of a full-size deck without sacrificing valuable line space. A rugged 1/4 HP blower motor, porcelainized interior and all-stainless exterior combine for years of trouble-free performance in the busiest commercial kitchens.
Key Features
- 30,000 BTU (9 kW) natural or propane gas burner
- Powerful 1/4 HP blower motor for rapid, even heat distribution
- Three chrome-plated racks with five rack positions
- Porcelain-coated sides, rear, deck & door liner for effortless cleanup
- Three-position switch: Cook • Cool-Down • Off
- Fan automatically stops when the door is opened for operator safety
- Heavy-duty, spring-balanced door with stamped inner liner for superior heat retention
- Stainless steel front, sides & top resist corrosion, dents and stains
- 6" stainless steel legs with adjustable bullet feet included
- NSF listed, CSA Flame & CSA Star certified
Performance & Capacity
- Interior: 26-1/2" W × 22-1/2" D × 14" H (673 × 572 × 356 mm)
- Holds (3) 18" × 26" full-size sheet pans front-to-back
- Zero-clearance sides & rear when installed against non-combustible walls
- Optional cook-and-hold computer controls available (contact us)
Specifications
| Gas Output | 30,000 BTU/hr (9 kW) |
|---|---|
| Motor | 1/4 HP single-speed convection blower |
| Interior Capacity | (3) full-size sheet pans |
| Interior Dimensions | 26-1/2" W × 22-1/2" D × 14" H |
| Overall Dimensions | 36" W × 28-7/8" D × 30" H |
| Shipping Weight | 480 lb (218 kg) |
| Gas Connection | 3/4" NPT • 5.0" W.C. Natural / 10.0" W.C. LP |
| Certifications | NSF • CSA Flame • CSA Star |
| Warranty | 1-year limited parts & labor |
Installation on a non-combustible surface is required. Allow 6" (152 mm) clearance from combustible walls on the sides when curb-mounted.
Why Choose Imperial Pro Series?
- Made in the USA for unmatched build quality
- Engineered to pair perfectly with Imperial Pro Series ranges, griddles & broilers
- Backed by Middleby’s nationwide service network
- Simple, intuitive controls keep your team focused on cooking—not on equipment quirks
Ask about fast, affordable equipment financing through Middleby Finance and keep your cash flow cooking.
