Imperial (Middleby) IR-2-G48-XB Pro Series Gas Ranges
Description
Imperial Pro Series 60" Gas Restaurant Range – 48" Griddle, 2 Open Burners & Standard Oven
Model IR-2-G48-XB | 179,000 BTU (52 kW)Replace a full cookline with one powerhouse. The Imperial IR-2-G48-XB delivers high-performance sauté, sear, griddle and bake abilities in a single, stainless-steel 60 inch footprint—ideal for busy restaurants, hotels and institutional kitchens that need versatility without the long hood run.
Key Advantages
- Two 32,000 BTU PyroCentric™ open burners each include a 7,000 BTU low-simmer ring for sauces and reductions.
- 48" griddle with a 3/4" thick, 21" deep polished steel plate and four 20,000 BTU burners for snap-hot, edge-to-edge heat.
- Chef-depth oven (26 1/2" W × 26" D × 14" H) fits full-size sheet pans—left-to-right or front-to-back—and cranks out 35,000 BTU.
- 3" wide grease trough, oversized grease can and full-width crumb tray lift out for fast cleanup.
- Heavy, cast-iron grates allow stock pots to slide easily across sections and onto the landing ledge.
- All-stainless front, sides, backguard, landing ledge and kick plate stand up to daily wear.
- 6" adjustable stainless legs ensure a level cooking surface on any floor.
- NSF, CE, CSA Flame & CSA Star certified for worldwide compliance.
Performance at a Glance
| Total Input | 179,000 BTU | 52 kW |
|---|---|
| Open Burners | 2 × 32,000 BTU PyroCentric™ (7,000 BTU simmer) |
| Griddle Burners | 4 × 20,000 BTU (under 48" plate) |
| Oven Burner | 35,000 BTU linear tube |
| Gas Connection | 3/4" NPT rear manifold Natural 5.0" W.C. | LP 10.0" W.C. |
Dimensions & Weights
| Overall Width | 60" / 1524 mm |
|---|---|
| Overall Depth | 31 1/2" / 800 mm |
| Height (to cooking surface / top of backguard) | 36" / 56 1/2" (914 / 1435 mm) |
| Oven Interior | 26 1/2" W × 26" D × 14" H |
| Shipping Weight | ≈ 1,045 lb / 472 kg |
| Crated Dimensions | 62 1/2" W × 39" D × 35" H |
| Warranty | 1-year parts & labor (factory authorized service) |
What’s Included
- (1) Chrome oven rack
- Open cabinet base with stainless shelf for sheet pans and smallwares
- Full-width removable crumb tray under open burners
- Cast-aluminum burner and griddle control knobs
Optional Upgrades
- 6" or 11" stainless backsplashes & salamander mounting channels
- Grooved or thermostatic griddle plate
- 6" locking casters for mobility
- Quick-disconnect gas hose & shut-off valve
- Extra chrome oven racks
Installation must conform to local codes. Provide 0" clearance to non-combustible surfaces or 8" (203 mm) to combustibles. Unit must be installed on legs/casters or on a 2" curb if curb-mounted.
