Imperial (Middleby) IHR-G12-M Spec Series Gas Ranges
Description
Imperial Spec Series 12" Modular Gas Griddle Top
Model IHR-G12-M | 30,000 BTU Add-A-UnitPack powerful performance into the smallest footprint on your cookline. The Imperial IHR-G12-M delivers 30,000 BTU of even, responsive heat across a highly-polished 12-inch griddle surface—perfect for searing, sautéing and all-day breakfast menus—while its modular Add-A-Unit design mates flush with other Spec Series equipment for a seamless, custom battery.
Key Features
- High-polished steel griddle plate distributes heat uniformly for consistent results.
- 30,000 BTU (9 kW) U-shaped burner located directly below the plate for fast recovery.
- Manual gas control with heat-shielded, cast-aluminum knob stands up to high-volume use.
- 4" (102 mm) full-length grease gutter feeds a 1-gal (3.8 L) removable can for quick clean-ups.
- Slide-out, full-width crumb tray catches crumbs & debris to simplify daily maintenance.
- Rugged stainless-steel front, sides, 6" backguard & extra-deep 7" landing ledge.
- Low-profile 11" height keeps the cooking surface easy to reach on counters or equipment stands.
- cETLus & NSF listed for gas safety and sanitation compliance.
Technical Specifications
| Griddle width | 12" / 305 mm |
|---|---|
| Overall dimensions (W × D × H) | 12" × 32" × 11" (305 × 813 × 279 mm) |
| Cooking surface | High-polish steel griddle plate |
| Heat output | 30,000 BTU / 9 kW |
| Burners | 1 U-shaped burner (one manual control) |
| Gas connection | 3/4" NPT rear |
| Manifold pressure | 5" W.C. Natural | 10" W.C. Propane |
| Grease management | 4" gutter with 1-gal (3.8 L) can, removable |
| Construction | Stainless steel front, sides, 6" backguard & 7" landing ledge |
| Certifications | cETLus, NSF |
| Shipping weight | 185 lb / 84 kg |
| Warranty | 1 year parts & labor |
Installation & Clearance
- For use on non-combustible surfaces only.
- 0" clearance from non-combustible surfaces; 6" (152 mm) from combustible surfaces.
- Ships for natural gas; field conversion to propane must be performed by a qualified technician.
Specifications subject to change without notice. Always consult the installation manual and local codes before installing.
