Imperial (Middleby) IHR-3HT-3-M Spec Series Gas Ranges
Description
Imperial Spec Series 36" Modular Gas Range
3 Open Burners + 3 Even-Heat Hot Tops • 240,000 BTU (70 kW)Built for chefs who demand maximum versatility from a compact footprint, the Imperial Spec Series 36" modular range pairs powerful open burners with even-heat hot tops – all wrapped in rugged stainless steel. Drop it onto a refrigerated base, chef station, or custom stand and unleash 240,000 BTU of searing, sautéing, and holding power.
Why You’ll Love It
- 3 anti-clog open burners rated at 40,000 BTU each with 7,000 BTU low-simmer feature
- 3 polished 12" even-heat hot tops – perfect for sauces, stocks, or holding pans
- Heavy-duty cast-iron “S” grates (standard) handle stock pots up to 14"
- Manual infinite-control valves for instant flame adjustment
- Full-width removable crumb tray speeds daily clean-up
- 7" deep stainless landing ledge keeps plates & pans within reach
- All-stainless front, sides, backguard, and welded seams for a professional, easy-to-clean finish
- cETLus & NSF listed for commercial kitchens
Open Burners
- One-piece venturi base—no gaskets to leak
- Anti-clog design protects the pilot from grease & debris
- Burners lift out for sink-side cleaning
- All-brass valve components for long service life
Even-Heat Hot Tops
- Thick, highly polished steel plates distribute heat edge-to-edge
- “U”-shaped 40,000 BTU burners under each 12" section
- Aeration baffles between burners boost recovery during peak periods
- Front-mounted individual gas valves for precise zone control
At-a-Glance Specs
| Model | IHR-3HT-3-M (Spec Series Modular) |
|---|---|
| Overall Width | 36" (914 mm) |
| Overall Depth | 34" (864 mm) |
| Overall Height | 16 1⁄4" (413 mm) to cook surface |
| Total Input | 240,000 BTU • 70 kW |
| Open Burners | 3 × 40,000 BTU (cast-iron, lift-out) |
| Hot Tops | 3 × 40,000 BTU, 12" wide plates |
| Gas Connection | 3⁄4" NPT rear manifold |
| Manifold Pressure | Nat 5.0" W.C. | LP 10.0" W.C. |
| Construction | Stainless front, sides, backguard, 7" landing ledge |
| Certifications | cETLus, NSF |
| Warranty | 1-Year parts & labor (see warranty statement) |
Need additional accessories such as a stainless stub back, salamander mounting kit, or 6" casters? Chat with us before checkout—we’ll configure the perfect Spec Series workstation for your line.
