Imperial (Middleby) IHPA-4-48-E Hot Plates
Imperial (Middleby) IHPA-4-48-E Hot Plates is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Description
Imperial IHPA-4-48-E 48" Electric Countertop Hot Plate
4 × 9" Sealed Round Plates • 8 kW Total OutputAdd high-performance sauté, simmer and finishing capacity to any cook line without sacrificing valuable floor space. The Imperial IHPA-4-48-E pairs rugged stainless-steel construction with four powerful 2 kW round plate elements, delivering range-quality speed and control in a slim, 19-3/8"-deep countertop design.
Why You’ll Love It
- 4 × 9" (229 mm) sealed round plate elements supply a solid, flat cooking surface for fast, even heating.
- Infinite heat controls let chefs fine-tune each burner independently for maximum menu flexibility.
- Solid top design keeps spills out of the chassis, cutting clean-up time to a minimum.
- Stainless steel front, top & sides with welded, polished seams stand up to daily abuse and wipe clean easily.
- 5" (127 mm) stainless landing ledge offers a convenient plating and staging area.
- Durable cast-aluminum knobs feature Valox™ grips that stay cool to the touch.
- 4" (102 mm) heavy-duty legs with adjustable feet ensure a level, NSF-acceptable installation.
- Certified cETLus, ETL-Sanitation & CE for broad code compliance.
- Backed by Imperial’s 1-year parts & labor warranty.
Ideal Applications
- Breakfast stations – rapid heating for omelets, griddle pans or stock pots.
- Sauté & finishing on busy cook lines.
- Mobile or kiosk operations that need full-range power in a compact footprint.
- Supplemental capacity during catering rushes or seasonal peaks.
Technical Specifications
Model | IHPA-4-48-E |
---|---|
Number of Elements | 4 × 2 kW round plates (total 8 kW) |
Plate Diameter | 9" / 229 mm |
Overall Dimensions | 48" W × 19-3/8" D × 10-3/4" H (1219 × 492 × 273 mm) |
Landing Ledge | 5" / 127 mm stainless steel |
Electrical (Standard) |
208 V 1 ɸ 39 A 208 V 3 ɸ 29 A 240 V 1 ɸ 33 A 240 V 3 ɸ 25 A |
Electrical (Option) | 480 V 3 ɸ 13 A * (export only) |
Total Connected Load | 8 kW |
Shipping Weight | 140 lb / 64 kg |
Clearances | 0" to non-combustible surfaces; 8" (203 mm) to combustibles |
Certifications | cETLus, ETL-Sanitation, CE |
Warranty | 1 year parts & labor |
Optional Accessories
- Stainless steel equipment stands (with or without undershelf).
- 6" (152 mm) locking casters for stands.
- Factory-wired 480 V configuration*.
*Additional charge applies. 480 V option intended for export markets.
