Imperial IHPA-2-12SU Step-Up Gas Hot Plate, 12"
64,000 BTU • 2 PyroCentric™ Open Burners • Countertop Range-Match ProfileDesigned for demanding commercial kitchens with limited line space, the Imperial IHPA-2-12SU delivers full-size range performance in a 12-inch countertop footprint. Two 32,000 BTU PyroCentric™ open burners— one in a raised step-up position—provide powerful, even heat and a true 7,000 BTU low-simmer setting, letting you sear, sauté and simmer with precision.
Why You’ll Love It
- 64,000 BTU total output: (2) 32,000 BTU anti-clog burners with dual rings of flame.
- Low simmer control: Each burner drops to 7,000 BTU for delicate sauces and reductions.
- Step-up design: Rear burner is elevated for better visibility and pan access on a crowded line.
- Cast-iron grates: Heavy-duty, anti-clog grates allow pots to slide effortlessly across sections and onto the 5" landing ledge.
- All-stainless exterior: Front, sides and ledge are easy to clean and match Imperial ranges & refrigerated bases.
- One standing pilot per burner: Instant ignition keeps service moving.
- Die-cast metal knobs: Built to withstand constant use and high heat.
- Full-width removable crumb tray: Speeds up end-of-shift clean-up.
- 4" adjustable legs: Level the unit on any countertop and provide 1" clearance for sanitation.
Engineered for Heavy Volume
- No gaskets or screws on burner assemblies—burners lift off for tool-free cleaning.
- Anti-clog pilot is recessed into the grate to stay protected from grease and food debris.
- Welded & polished seams enhance strength and give a professional, seamless look.
Specifications
| Model | IHPA-2-12SU |
|---|---|
| Overall Width | 12" (305 mm) |
| Overall Depth | 31-3/8" (797 mm) |
| Overall Height | 14-3/4" (375 mm) | 19-1/2" (495 mm) to grate top |
| Number of Burners | 2 open (front + step-up rear) |
| Total BTU | 64,000 BTU/hr | 19 kW |
| Gas Connection | 3/4" NPT rear manifold |
| Manifold Pressure | Natural 5.0" W.C. | Propane 10.0" W.C. |
| Clearances | 0" sides/back (non-combustible) • 8" (203 mm) combustible surfaces |
| Shipping Weight | 90 lb (41 kg) |
| Certifications | CSA Flame • CSA Star • NSF • CE |
Popular Options & Accessories
- Stainless steel equipment stand (with or without 6" casters)
- 10" stainless steel wok ring
- Interchangeable sauté or wok burner heads
- 3/4" NPT gas shut-off valve
- Quick-disconnect & flexible gas hose kit
Warranty: 1-year parts & labor when installed, operated and maintained per Imperial guidelines.
Need a larger configuration? Imperial IHPA hot plates are also available in 24", 36" and 48" widths. Contact us for details and lead times.
$2,746.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Powerful Imperial Middleby 12" countertop gas hot plate—64,000 BTU, dual 32k burners, cast iron grates, stainless steel, NSF/CSA certified.
Manufacturer
Imperial (Middleby)
Certifications
NSF, CE, CSA Star, CSA Flame
Height
15.13in
Width
12.0in
Depth
31.38in
Shipping Weight
90.0lbs
Burner Qty
(1) open burner, (1) step-up open burner
Width (side - side)
12 - 23"
Legs
with legs
Top and Front Finish
stainless steel front & sides
Specifications
Hotplate, gas, countertop, 12"W, (1) 32,000 BTU open burner, (1) 32,000 BTU step-up open burner, cast iron grates, removable crumb tray, stainless steel front, sides & 5"D landing ledge, 4" legs with adjustable feet, 64,000 BTU, 19kW, CSA Flame, CSA Star, NSF, CE
