Imperial (Middleby) IFSSP650 Gas Fryers
Description
Imperial IFSSP650 Six-Bank 50 lb Gas Fryer System
840,000 BTU • Built-In Space-Saver Filter • Snap-Action ThermostatsMaximize throughput while minimizing floor space with Imperial’s IFSSP650 fryer battery. Six 50-lb tube-fired fryers are seamlessly joined over a single, under-cabinet filtration system, giving you 300 lb total oil capacity, faster turnarounds, and cleaner oil—all in one polished, mobile workstation.
Why You’ll Love It
- Six independent frypots – tackle high-volume menus or dedicate vats to allergen-free cooking.
- Integrated Space-Saver filter – no external carts; filter, polish & return oil in minutes.
- 5.5 GPM roller pump – 1/3 HP motor rapidly circulates oil and can discharge up to 20 ft away.
- Snap-action thermostats – quick, accurate recovery keeps temperatures rock-steady.
- Stainless steel everywhere – frypots, front & sides resist corrosion and wipe clean fast.
- Factory-installed casters – roll the entire battery for cleaning or line re-configuration.
- Ready to run – joiner strips & filter starter kit included.
- Certified safe – CSA Flame, CSA Star, NSF & CE listings.
At-a-Glance Specifications
| Model | IFSSP650 (6-Battery) |
|---|---|
| Oil Capacity | 50 lb per frypot × 6 = 300 lb total (41 L each) |
| Heat Source | Natural or LP gas, tube-fired |
| Total BTU | 840,000 BTU/hr |
| Filtration System | Built-in Space-Saver; 5.5 GPM roller pump, 1/3 HP motor |
| Thermostat Type | Snap-action, millivolt controls (no external power required for heat) |
| Electrical | 120 V / 60 Hz / 1-ph, 6.8 A (pump & controls) |
| Cabinet Width | 93" (2362 mm) |
| Depth × Height | 35" D × 45 3/4" H (889 mm D × 1162 mm H) |
| Included Accessories | Casters (front locking), joiner strips, filter starter kit |
| Certifications | CSA Flame, CSA Star, NSF, CE |
| Warranty | 1-year parts & labor; 5-year pro-rated fry tank |
Boost Productivity & Cut Costs
- Filter multiple vats in one cycle—keep cooking while you polish the next frypot.
- Cleaner oil = longer life & better-tasting food, lowering your annual oil spend.
- Tubular burners & large heat transfer area deliver rapid recovery for peak rushes.
- Internal plumbing and quick-disconnect return line reduce mess and burn risk.
Imperial recommends a 0" clearance from non-combustible surfaces and 6" (152 mm) from combustible surfaces. Install on casters or legs over a non-combustible floor in accordance with local codes.
