Imperial (Middleby) IFSSP575T Gas Fryers
Description
Imperial IFSSP575 Space Saver 5-Battery Gas Fryer & Filter System
375 lb total oil capacity | 875,000 BTU | Electronic ThermostatsDesigned for high-volume kitchens that refuse to sacrifice floor space, the Imperial IFSSP575 combines five full-size 75 lb tube-fired fryers with an integrated “under-the-cabinet” Space Saver filter system. Fast filtration, rock-solid temperature recovery and rugged stainless-steel construction keep production lines moving—shift after shift, day after day.
Why this fryer system stands out
- Built-in Space Saver filter—no separate floor unit needed; drains & returns are internally plumbed.
- 5.5 GPM roller pump (1/3 HP) filters a full frypot in minutes and can discharge oil up to 20 ft away.
- Electronic thermostats deliver fast heat recovery and precise control for consistent results.
- Massive output—five 75 lb fryers deliver a combined 875,000 BTU of tube-fired power for peak-hour demand.
- Stainless steel everywhere—frypots, front, sides and continuous cabinet for durability and easy cleanup.
- Ready to roll—ships on heavy-duty casters and includes joiner strips plus a filter starter kit.
- Certified & safe—CSA Flame, CSA Star, NSF & CE listed.
At-a-glance specs
| Model | IFSSP575 |
|---|---|
| Number of fryers | 5 (batteried) |
| Oil capacity | 75 lb (51 L) per frypot | 375 lb (189 L) total |
| Gas input | 875,000 BTU/hr total (175,000 BTU each) |
| Filtration system | Integrated Space Saver; 5.5 GPM roller pump, 1/3 HP motor |
| Thermostat type | Electronic (snap-action optional) |
| Cabinet construction | Stainless steel frypots, front & sides; 5″ front landing ledge |
| Overall dimensions | 97-1/2″ W × 39″ D × 45-3/4″ H |
| Electrical (pump) | 120 V / 60 Hz / 1-ph, 6.8 A | 6 ft cord with 3-prong plug |
| Shipping weight | Approx. 1,400 lb (635 kg) |
| Certifications | CSA Flame, CSA Star, NSF, CE |
| Standard inclusions | Casters, joiner strips, filter starter kit |
| Warranty | 1 yr parts & labor | 5 yr pro-rated fry tank |
Popular options & accessories
- Automatic or manual basket lifts
- Computer controls
- Stainless steel tank covers, side drain shelf or side splash
- Gas shut-off valve (3/4″ NPT)
- 40# filter paper, 20 micron (100-sheet box)
- Manual timer kit
Imperial reserves the right to make product improvements without prior notice. Always consult your local codes and the installation manual before ordering or installing equipment.
