Imperial (Middleby) IFSSP575-OP-T Gas Fryers
Description
Imperial IFSSP575-OP-T Five-Battery 75 lb Open-Pot Gas Fryer w/ Space Saver Filter System
875,000 BTU • Electronic Thermostat • cETLus & ETL-SanitationBuilt for relentless dinner rushes, the IFSSP575-OP-T combines five full-size, 75 lb open-pot fryers with a fully integrated Space Saver filtration cabinet. You get the production of a battery line, the convenience of push-button filtering and the consistency of an electronic thermostat—all in a single, easy-to-wheel footprint.
Key Features & Benefits
- High-volume performance – 375 lb total oil capacity and 875,000 BTU of gas input power through five independent frypots.
- Space Saver filter system sits beneath the fryers, freeing up cookline real estate.
- 5.5 GPM roller pump (1/3 HP) rapidly filters and returns oil; powerful enough to discharge to a disposal vat up to 20 ft away.
- Stainless steel frypots, front & sides stand up to daily commercial abuse and wipe clean fast.
- Electronic thermostat delivers precise, recovery-ready temperature control.
- Includes casters, joiner strips & filter starter kit for plug-and-play installation.
- Rear gas manifold with single-point connection simplifies utility hook-ups.
Technical Specifications
| Model | IFSSP575-OP-T |
|---|---|
| Fryer configuration | Five (5) open-pot fryers, common filter base |
| Oil capacity | 75 lb (51 L) per pot | 375 lb total |
| Total gas input | 875,000 BTU/hr |
| Thermostat type | Electronic (solid-state) |
| Filtration pump | 5.5 GPM roller pump, 1/3 HP motor |
| Electrical (pump) | 120 V / 60 Hz / 1-Phase, 6.8 A (6 ft cord & 3-prong plug included) |
| Exterior construction | Stainless steel frypots, cabinet front & sides; 5" landing ledge |
| Overall dimensions | 97-1/2" W × 39" D × 45-3/4" H (2477 × 991 × 1162 mm) |
| Shipping weight | 1,400 lb (635 kg) |
| Clearances | 0" sides/rear to non-combustible surfaces; 6" to combustible |
| Certifications | cETLus, ETL-Sanitation |
| Warranty | 1-year parts & labor; 5-year pro-rated frypot |
Designed for Maximum Uptime
- Fast in-cabinet filtering encourages frequent oil polishing, extending oil life and flavor quality.
- Positive-latching filter paper holder keeps media flat for optimal filtration.
- Quick-disconnect return hose lets staff polish multiple pots in minutes—no lifting, no mess.
- Casters provide full mobility for cleaning and maintenance.
Need even more automation? Factory-installed basket lifts, side drain shelves, splash guards and other accessories are available—ask your product specialist for details.
