Imperial (Middleby)  |  SKU: IFSSP575

Imperial (Middleby) IFSSP575 Gas Fryers

$46,997.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Training video Owner's manual Warranty sheet
Related Searches
Fryers Gas Fryers

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Imperial IFSSP575 Space Saver 5-Battery Gas Fryer / Filter System

Five 75 lb frypots • 875,000 BTU • Built-in 5.5 GPM roller pump

Boost output without giving up floor space. The Imperial IFSSP575 combines five high-performance 75 lb tube-fired fryers with an integrated under-cabinet filtration system, so you can filter, drain and return oil in minutes—right where the frying happens. Heavy-duty stainless construction, simple snap-action thermostats and a massive 875,000 BTU total input make this battery a powerhouse for chicken, fish, fries and more.

Why this fryer battery rocks

  • True space saver – filtration is tucked under the cabinet; no extra footprint required.
  • 5.5 GPM roller pump with 1/3 HP motor filters a full frypot fast and can discharge oil up to 20 ft.
  • Snap-action thermostats (200-400 °F) deliver quick recovery and consistent product quality.
  • Precision-welded stainless steel frypots backed by a 5-year limited tank warranty.
  • Continuous stainless cabinet with 5" landing ledge creates a professional, easy-clean work zone.
  • Rear gas manifold provides a single-point gas connection for simplified installation.
  • Factory-installed casters, joiner strips & filter starter kit included—roll in and start frying.

Integrated “Space Saver” filtration

  • Filter pan sits directly beneath the fryers—no external cart to maneuver.
  • Positive-latching paper holder keeps media flat for maximum oil return.
  • Quick-disconnect return line makes re-seating the pan fast and splash-free.
  • All drain & return plumbing is internal for a safer, cleaner kitchen.

Popular factory options (sold separately)

  • Automatic or manual basket lifts
  • Tank covers, side drain shelf or side splash
  • 3/4" NPT gas shut-off valve
  • Manual timer & replacement filter paper (20 micron, 40 lb)

Specifications

Oil capacity (5) × 75 lb (51 L) frypots
Total BTU input 875,000 BTU/hr natural or LP gas
Filtration pump 5.5 GPM roller pump, 1/3 HP motor
Electrical (pump) 120 V / 60 Hz / 1-phase, 6.8 A, 6-ft cord & 3-prong plug
Exterior dimensions 97 1⁄2" W × 39" D × 45 3⁄4" H (2477 × 991 × 1162 mm)
Clearances 0" sides/back to non-combustible, 6" to combustible; non-combustible floor with casters
Ship weight Approx. 1400 lb (635 kg)
Certifications CSA Flame, CSA Star, NSF, CE
Warranty 1-year parts & labor; 5-year pro-rated frypot warranty

Gas & electrical connections must be performed by qualified personnel. Specs subject to change without notice.

Features & Specs

Manufacturer

Imperial (Middleby)

Certifications

NSF, CE, CSA Star, CSA Flame

Height

45.75in

Width

97.5in

Depth

39.0in

Shipping Weight

1400.0lbs

Controls

thermostatic controls

Exterior Finish

stainless steel front & sides

Fat Capacity (approximate)

75 lbs each

With or without basket lifts

without basket(s)

Fryer Quantity

(5) tanks

Filter

built-in filter

Fry pot

stainless steel

Specifications

Fryer, gas, floor model, (5) battery, 75 lb. capacity each, built in space saver filter system, 5.5 GPM roller pump, snap action thermostat, includes: joiner strips & filter starter kit, stainless steel frypot, front & sides, casters, 120v/60/1-ph, 6.8 amps, 1/3 HP, 875,000 BTU, CSA Flame, CSA Star, NSF, CE
