Imperial (Middleby)  |  SKU: IFSSP550

Imperial (Middleby) IFSSP550 Gas Fryers

$38,344.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Training video Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Fryers Gas Fryers

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Imperial IFSSP550 5-Battery 50 lb Gas Fryer with Built-In Space Saver Filter System

250 lb total oil capacity • 700,000 BTU • Snap-Action Thermostats

Power through your highest-volume frying shifts while protecting oil life and kitchen space. The Imperial IFSSP550 combines five independent 50 lb tube-fired fryers with a fully integrated Space Saver™ automatic filtration system, delivering continuous productivity, cleaner-tasting food and lower operating costs in one seamless, easy-to-move cabinet.

Why You’ll Love It

  • True workhorse capacity – five frypots supply a total of 250 lb (115 L) oil volume to crush peak-hour demand.
  • Under-fryer filtration – no extra floor space needed; drains and returns are internally plumbed for a fast, mess-free cycle.
  • 5.5 GPM roller pump – 1/3 HP motor filters an entire system in minutes and can evacuate oil up to 20 ft for disposal.
  • Snap-action thermostats ensure tight temperature control for perfectly crisp results batch after batch.
  • All stainless construction (frypots, front & sides) plus continuous cabinet and 5" landing ledge for a polished, durable station.
  • Ready to roll – factory-installed casters, joiner strips and a filter starter kit get you frying (and moving) right out of the box.
  • High-efficiency tube burners deliver a combined 700,000 BTU for rapid recovery and higher through-put.

Perfect For

  • High-volume QSR and fast-casual chains
  • College, stadium & arena concessions
  • Ghost kitchens needing maximum output in minimum space
  • Any operation looking to extend oil life and cut downtime

Technical Specifications

Model IFSSP550
Frypot Count & Capacity 5 frypots  |  50 lb (41 L) each  |  250 lb total
Heat Source Gas, tube-fired burners
Total Input 700,000 BTU/hr
Temperature Control Snap-action thermostats (add “T” for electronic or “C” for computer controls)
Integrated Filtration Space Saver™ filter pan with positive-latching paper holder
Pump & Motor 5.5 GPM roller pump  |  1/3 HP
Electrical (pump) 120 V / 60 Hz / 1-phase, 6.8 A (6 ft cord & NEMA 5-15P plug included)
Gas Connection Rear manifold, single 3/4" NPT
Exterior Dimensions 77-1/2" W × 35" D × 45-3/4" H (1969 × 889 × 1162 mm)
Shipping Weight 1,315 lb (596 kg)
Clearances 0" non-combustible  |  6" combustible surfaces
Certifications CSA Flame, CSA Star, NSF, CE
Warranty 1-year parts & labor • 5-year pro-rated fry tank

What’s in the Box

  • IFSSP550 fryer/filter assembly with casters installed
  • Joiner strips (maintain a seamless battery)
  • Filter starter kit (paper & powder)
  • User & installation manual

Popular Factory Options

  • Automatic or manual basket lifts
  • Stainless steel tank covers, side drain shelf or splash guards
  • 3/4" NPT gas shut-off valve
  • Manual timer kit
Installation Notice: For use only on non-combustible floors. Follow all local gas and electrical codes. Professional installation is required to maintain warranty coverage.

Imperial reserves the right to modify specifications without notice. Please confirm gas type and any optional accessories at time of order.

Features & Specs

Manufacturer

Imperial (Middleby)

Certifications

NSF, CE, CSA Star, CSA Flame

Height

45.75in

Width

77.5in

Depth

35.0in

Shipping Weight

1315.0lbs

Fryer Quantity

(5) tanks

Exterior Finish

stainless steel front & sides

Controls

thermostatic controls

With or without basket lifts

without basket(s)

Fat Capacity (approximate)

50 lbs each

Filter

built-in filter

Fry pot

stainless steel

Specifications

Fryer, gas, floor model, (5) battery, 50 lb. capacity each, built in space saver filter system, 5.5 GPM roller pump, snap action thermostat, includes: joiner strips & filter starter kit, stainless steel frypot, front & sides, casters, 120v/60/1-ph, 6.8 amps, 1/3 HP, 700,000 BTU, CSA Flame, CSA Star, NSF, CE
