Imperial (Middleby)  |  SKU: IFSSP450EU

Imperial (Middleby) IFSSP450EU Electric Fryers

$51,045.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Training video Parts manual Owner's manual Middleby financial flyer Warranty sheet
Related Searches
Food Prep Equipment Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Imperial IFSSP450EU 50 lb Electric Fryer Battery with Space Saver Filter System

4 Fryers • Tilt-Up Elements • Snap-Action Thermostats • 5.5 GPM Roller Pump

Maximize production without sacrificing floor space. The Imperial IFSSP450EU unites four independent 50 lb electric fryers with an integrated Space Saver filter system, keeping oil fresh and food quality high in the busiest commercial kitchens.

Key Features

  • Four 50 lb (41 L) stainless-steel frypots — 200 lb total oil capacity.
  • Tilt-up immersed elements swing clear of the tank for fast, safe cleaning and maintenance.
  • Built-in Space Saver filter sits under the battery, reclaiming valuable floor space.
  • 5.5 GPM roller pump with a 1/3 HP motor filters an entire battery in minutes and can discharge up to 20 ft.
  • Snap-action thermostats deliver quick recovery and tight temperature accuracy.
  • Positive-latching paper holder and quick-disconnect return line streamline filtration.
  • Continuous stainless-steel cabinet, front and sides stand up to heavy-duty use.
  • Heavy-duty casters (front locking) plus factory-supplied joiner strips create a seamless, mobile unit.
  • Ships with a filter starter kit — ready for first-day operation.
  • Certifications: cETLus, CSA Flame, CSA Star, CSA-Sanitation, CE.

Specifications

Model IFSSP450EU
Oil Capacity 4 × 50 lb (41 L) frypots
Overall Width 62 in (1575 mm)
Depth 34 in (864 mm)
Height 44 1/8 in (1121 mm)
Electrical (per fryer) 208 V / 3 ph / 60 Hz / 42.38 A
240 V / 3 ph / 60 Hz / 36.73 A
480 V / 3 ph / 60 Hz / 18.36 A*
Filter Electrical 115 V / 1 ph / 60 Hz / 6.8 A (6 ft cord & 3-prong plug included)
Pump Output 5.5 GPM roller pump, 1/3 HP motor
Ship Weight 1062 lb (482 kg)
Clearances 0″ from non-combustible surfaces; 6″ (152 mm) from combustible
Warranty 1 year parts & labor; 5-year pro-rated frypot warranty

*480 V configuration is available for export markets only.

Need more capacity? Up to six fryers can be batteried to a single Space Saver filter system—contact us for custom configurations.

Installation Note: Unit must be installed on a non-combustible floor and wired by a qualified electrician in accordance with all applicable codes.

Features & Specs

Manufacturer

Imperial (Middleby)

Certifications

CE, cETLus, CSA-Sanitation, CSA Star, CSA Flame

Height

44.13in

Width

62.0in

Depth

34.0in

Shipping Weight

1062.0lbs

With or without basket lifts

without basket(s)

Fry pot

stainless steel

Controls

thermostatic controls

Filter

built-in filter

Fryer Quantity

(4) tanks

Fat Capacity (approximate)

50 lbs each

Exterior Finish

all stainless steel exterior

Specifications

Fryer, electric, floor model, (4) battery, 50 lb. capacity each, tilt-up elements, built-in space saver filter system, 5.5 GPM roller pump, snap action thermostat, includes: joiner strips & filter starter kit, stainless steel frypot, front & sides, casters, 1/3 HP, cETLus, CSA Flame, CSA Star, CSA-Sanitation, CE
