IMC/Teddy SFT18-13-SG-ADA Shallow Floor Trough with Drain, 14 ga 304 Stainless Steel, Subway Grating, 156"W x 18"D x 2" Deep

SKU: SFT18-13-SG-ADA
$11,632.20
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Cleaning & Janitorial Supplies Commercial Faucets & Plumbing Equipment Floor Drains Floor Drains & Troughs Floor Maintenance IMC/Teddy New Arrivals Plumbing & Water Treatment Sinks & Handwashing Stations

The IMC/Teddy SFT18-13-SG-ADA is a shallow floor trough measuring 156 inches wide, 18 inches deep, and 2 inches overall deep. It is constructed from 14 ga 304 stainless steel and includes a drain with SG-ADA subway grating.

  • Designed for food preparation facilities where floor thickness limits trough depth to 2 inches.
  • SG-ADA grating uses stainless steel bars spaced 1/2 inch apart.
  • Integral coves and a 1/4-inch-per-foot pitch direct water toward the waste outlet.
  • A recessed flange supports floor tile and provides a grout pocket.
  • TIG-welded joints and a brush satin finish are specified for the SFT trough.
  • A perforated waste basket is provided at each drain.

Overall Dimensions:

156.0"W x 18.0"D x 2.0"H

Product Weight:

325.0 lb

Shallow 2-inch profile

The trough is 2 inches deep overall for installations where floor thickness limits trough depth.

304 stainless steel construction

The trough is constructed from 14 ga 304 stainless steel.

SG-ADA subway grating

The included grating is SG-ADA subway-style grating with stainless steel bars spaced 1/2 inch apart.

Pitched drainage

Integral coves and a 1/4-inch-per-foot pitch direct water toward the waste outlet.

Recessed flange

The recessed flange supports floor tile and provides a grout pocket.

Drain assembly

The trough is specified with a drain, a 6 1/2-inch OD waste outlet, and a 4-inch OD tailpiece.

Perforated waste basket

SFT documentation specifies a perforated waste basket at each drain.

Welded construction

Joints are TIG welded and specified as leak-proof, with exposed surfaces finished brush satin.

Overall depth 2 in
Width (long side) 156 in
Depth (short side) 18 in
Weight 325 lb
Trough construction 14 ga 304 stainless steel
Grate type SG-ADA subway-style grating
Grate construction Type 300 series stainless steel bars
Pan type Non anti-splash
Drain With drain
Waste outlet 6 1/2 in OD
Tailpiece 4 in OD
Drainage pitch 1/4 in per ft toward the waste outlet
Waste basket Perforated waste basket provided at each drain
Surface finish Brush satin

Documents

PDF Cutsheet PDF Download PDF Seepage flange installation manual PDF Download PDF Floor trough installation manual PDF Download PDF Floor troughs brochure PDF Download

Frequently Asked Questions

The trough measures 156 inches wide, 18 inches deep, and 2 inches deep overall.
It is constructed from 14 ga 304 stainless steel.
Yes. The authoritative specification identifies this model as with drain; SFT documentation specifies a 6 1/2-inch OD waste outlet with a 4-inch OD tailpiece.
The model includes SG-ADA subway-style grating with stainless steel bars spaced 1/2 inch apart.
No. The authoritative category attribute identifies the pan type as non anti-splash.
The SFT trough is pitched 1/4 inch per foot toward the waste outlet and has integral coves.
SFT documentation specifies use in food preparation facilities where floor thickness limits trough depth to 2 inches.
