Play manufacturer video for IMC/Teddy SFT-2196-PFG-ADA Shallow Floor Trough with Drain, 96"W x 21"D x 2" Deep, Stainless Steel, Blue Fiberglass GratingIMC/Teddy SFT-2196-PFG-ADA Shallow Floor Trough with Drain, 96"W x 21"D x 2" Deep, Stainless Steel, Blue Fiberglass Grating
The IMC/Teddy SFT-2196-PFG-ADA is a shallow floor trough measuring 96 inches wide, 21 inches deep, and 2 inches overall deep. It is constructed from 14-gauge 304 stainless steel and includes a drain with blue PFG-ADA pultruded fiberglass grating.
- Shallow design: 2-inch overall trough depth for applications where floor thickness limits trough depth.
- Drainage: Integral pitch directs water toward the waste outlet, and a perforated waste basket is provided at the drain.
- Grating: Blue PFG-ADA pultruded fiberglass grating with an ADA-compliant 0.4-inch bar spacing.
- Construction: Integral coves, recessed flange, and TIG-welded stainless steel joints.
Overall Dimensions:
96.0"W x 21.0"D x 2.0"HProduct Weight:
360.0 lbShallow 2-inch design
The trough is 2 inches deep overall for food preparation facilities where floor thickness limits trough depth.
Stainless steel construction
Constructed from 14-gauge 304 stainless steel.
Blue PFG-ADA grating
Includes blue pultruded fiberglass grating with ADA-compliant grating bars spaced 0.4 inches apart.
Integrated drainage
The trough is pitched 1/4 inch per foot toward a 6.5-inch OD waste outlet and includes a 4-inch OD tailpiece and perforated waste basket.
Integral coves and recessed flange
Integral coves support drainage, while the recessed flange supports floor tile and provides a grout pocket.
TIG-welded joints
The SFT trough guide specifies TIG-welded, leak-proof joints with exposed surfaces finished in brushed satin.
