IMC/Teddy

IMC/Teddy SFT-12120-PFG-ADA Shallow Floor Trough, 120"W x 12"D x 2" Deep, 14 ga Stainless Steel with Fiberglass Grating

SKU: SFT-12120-PFG-ADA
$6,336.00
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The IMC/Teddy SFT-12120-PFG-ADA is a shallow floor trough measuring 120 inches wide, 12 inches deep, and 2 inches in overall pan depth.

It features 14-gauge 304 stainless steel construction, integral coves, a pitched drainage floor, an included drain, and blue PFG-ADA pultruded fiberglass grating.

  • Designed for food preparation facilities where floor thickness limits trough depth to 2 inches.
  • The trough is pitched 1/4 inch per foot toward the waste outlet.
  • The PFG-ADA grating has blue bars with 0.4-inch spacing and an anti-slip surface.

Overall Dimensions:

120.0"W x 12.0"D x 2.0"H

Product Weight:

230.0 lb

Shallow profile

The trough is 2 inches deep overall for applications where floor thickness limits trough depth.

Stainless steel construction

The trough is constructed from 14-gauge 304 stainless steel.

Integrated drainage

Integral coves and a 1/4-inch-per-foot pitch direct water toward the waste outlet.

Waste outlet

The SFT specification includes a 6.5-inch OD waste outlet with a 4-inch OD tailpiece.

PFG-ADA grating

Blue pultruded fiberglass grating is supplied with 0.4-inch bar spacing and an anti-slip surface.

Welded construction

SFT trough joints are TIG welded and leak-proof, with exposed surfaces finished in brushed satin.

Waste basket

A perforated waste basket is provided at each drain.

Related Searches

Best Sellers Cleaning & Janitorial Supplies Commercial Faucets & Plumbing Equipment Floor Drains Floor Drains & Troughs Floor Maintenance IMC/Teddy New Arrivals Plumbing & Water Treatment Sinks & Handwashing Stations
Width (long side) 120 in
Depth (short side) 12 in
Pan depth 2 in
Trough construction 14-gauge 304 stainless steel
Grating construction PFG-ADA pultruded fiberglass, blue
Pan type Non anti-splash
Drain Included
Waste outlet 6.5 in OD with 4 in OD tailpiece
Trough pitch 1/4 in per foot toward waste outlet
Grating bar spacing 0.4 in
Product weight 230 lb

Documents

PDF Cutsheet PDF Download PDF Floor troughs brochure PDF Download PDF Seepage flange installation manual PDF Download PDF Floor trough installation manual PDF Download

Frequently Asked Questions

The trough measures 120 inches wide by 12 inches deep, with a 2-inch overall pan depth.
It is made from 14-gauge 304 stainless steel.
The product includes blue PFG-ADA pultruded fiberglass grating with 0.4-inch bar spacing.
Yes. The authoritative product specification identifies the trough as including a drain.
Integral coves and a 1/4-inch-per-foot pitch direct water toward a 6.5-inch OD waste outlet with a 4-inch OD tailpiece.
It is intended for food preparation facilities where floor thickness limits trough depth to 2 inches.
The authoritative product attributes identify the pan type as non anti-splash.
