IMC/Teddy SEC-LFT12-16-PFG-ADA Security Floor Trough with Drain, 192"W x 12"D x 4" Deep, 14 ga Stainless Steel, Blue Fiberglass Grates

SKU: SEC-LFT12-16-PFG-ADA
$8,874.00
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Cleaning & Janitorial Supplies Commercial Faucets & Plumbing Equipment Floor Drains Floor Drains & Troughs Floor Maintenance IMC/Teddy New Arrivals Plumbing & Water Treatment Sinks & Handwashing Stations

The IMC/Teddy SEC-LFT12-16-PFG-ADA is a 192-inch security floor trough with a 14 ga type 304 stainless steel trough, drain, and blue PFG-ADA-SEC security pultruded fiberglass grating.

  • Dimensions: 192 in wide x 12 in deep x 4 in overall height.
  • Construction: 14 ga type 304 stainless steel trough.
  • Grating: Blue PFG-ADA-SEC security pultruded fiberglass grating.
  • Security design: The correctional frame secures the grating to the ledge with a special locking device and tamperproof screws.
  • Drainage: The SEC design is pitched to a 6 1/2 in OD waste outlet with a 4 in OD tailpiece.

Overall Dimensions:

192.0"W x 12.0"D x 4.0"H

Product Weight:

272.0 lb

Security grating retention

A correctional frame secures the grating to the ledge with a special locking device and tamperproof screws.

Stainless steel construction

The trough is constructed from 14 ga type 304 stainless steel.

Blue fiberglass grating

The unit uses PFG-ADA-SEC security pultruded fiberglass grating in blue.

Drainage outlet

The SEC design is pitched to a 6 1/2 in OD waste outlet with a 4 in OD tailpiece.

Pan type

The pan type is non anti-splash.

Brushed satin finish

Exposed surfaces of the SEC trough design have a brushed satin finish.

Overall width 192 in
Short-side depth 12 in
Pan depth 4 in
Trough construction 14 ga type 304 stainless steel
Grating construction PFG-ADA-SEC security pultruded fiberglass, blue
Pan type Non anti-splash
Drain Included
Drain outlet 6 1/2 in OD waste outlet with 4 in OD tailpiece
Finish Brushed satin
Weight 272 lb

Documents

PDF Cutsheet PDF Download PDF Seepage flange installation manual PDF Download PDF Floor troughs brochure PDF Download PDF Security brochure PDF Download PDF Floor trough installation manual PDF Download

Frequently Asked Questions

The trough is 192 in wide, 12 in deep on the short side, and 4 in overall height.
It is constructed from 14 ga type 304 stainless steel.
It uses blue PFG-ADA-SEC security pultruded fiberglass grating.
Yes. The authoritative specification identifies this model as supplied with a drain.
A correctional frame secures the grating to the ledge with a special locking device and tamperproof screws.
No. The authoritative pan type is non anti-splash.
