Play manufacturer video for IMC/Teddy SEC-FT18-24-SG Security Stainless Steel Floor Trough with Drain, Subway Grating, 288"W x 18"D x 4" DeepIMC/Teddy SEC-FT18-24-SG Security Stainless Steel Floor Trough with Drain, Subway Grating, 288"W x 18"D x 4" Deep
The IMC/Teddy SEC-FT18-24-SG is a security floor trough measuring 288 inches wide by 18 inches deep with a 4-inch trough depth. It is constructed from 14-gauge type 304 stainless steel and includes a drain and SG-SEC security subway grating.
- Designed for correctional, penal, and justice-building applications.
- The security frame secures the grating to the ledge, while a special locking device and tamperproof screws hold the grating in place.
- Integral coves and pitch direct drainage toward the waste outlet.
- TIG-welded, leakproof joints and a brush satin finish are specified for the exposed surfaces.
- A recessed flange supports floor tile and provides a grout pocket.
Overall Dimensions:
288.0"W x 18.0"D x 4.0"HProduct Weight:
648.0 lbType 304 stainless steel construction
The trough is constructed from 14-gauge type 304 stainless steel.
Security grating retention
A correctional frame secures the grating to the ledge, and a special locking device with tamperproof screws holds it in place.
Drainage design
Integral coves and pitch direct drainage toward the waste outlet; the model includes a drain.
SG-SEC subway grating
The specified grating is SG-SEC security subway grating constructed of stainless steel.
TIG-welded joints
The joints are TIG welded and leakproof.
Recessed flange
The recessed flange supports floor tile and provides a grout pocket.
Brush satin finish
Exposed surfaces are finished in brush satin.
Non anti-splash pan
The authoritative pan type is non anti-splash.
