IMC/Teddy FT18-16-SG-ADA Stainless Steel Floor Trough with Drain and Subway Grating, 192"W x 18"D x 4" Deep

SKU: FT18-16-SG-ADA
$14,316.60
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The IMC/Teddy FT18-16-SG-ADA is a 192 in wide floor trough constructed from 14 ga 304 stainless steel. It includes a drain and SG-ADA subway-style stainless steel grating.

  • Dimensions: 192 in wide x 18 in deep x 4 in high.
  • Drainage: FT trough design with integral coves and a pitch toward the waste outlet.
  • Grating: SG-ADA subway-style grating with 1/2 in bar spacing.
  • Pan type: Non anti-splash.

Overall Dimensions:

192.0"W x 18.0"D x 4.0"H

Product Weight:

448.0 lb

14 ga 304 stainless steel construction

The trough is specified in 14 ga 304 stainless steel.

SG-ADA subway-style grating

The product includes SG-ADA subway-style stainless steel grating with 1/2 in bar spacing.

Integral drainage design

FT trough documentation describes integral coves and a 1/4 in per foot pitch toward the waste outlet.

Non anti-splash pan

The authoritative pan type is non anti-splash.

TIG-welded joints

FT trough documentation states that the joints are TIG welded and leak-proof.

Recessed flange

The recessed flange supports floor tile and provides a grout pocket.

Related Searches

Best Sellers Cleaning & Janitorial Supplies Commercial Faucets & Plumbing Equipment Floor Drains Floor Drains & Troughs Floor Maintenance IMC/Teddy New Arrivals Plumbing & Water Treatment Sinks & Handwashing Stations
Trough construction 14 ga 304 stainless steel
Grate construction Stainless steel grates
Grate type SG-ADA subway-style grating
Pan type Non anti-splash
Drain Included
Trough pitch 1/4 in per ft toward waste outlet
Waste outlet 6.5 in OD
Tailpiece 4 in OD x 3 in long
Overall width 192 in
Overall depth 18 in
Overall height 4 in
Weight 448 lb

Documents

PDF Cutsheet PDF Download PDF Floor troughs brochure PDF Download PDF Floor trough installation manual PDF Download PDF Seepage flange installation manual PDF Download

Frequently Asked Questions

The trough is 192 in wide, 18 in deep, and 4 in high.
It is specified as 14 ga 304 stainless steel.
The product includes SG-ADA subway-style stainless steel grating with 1/2 in bar spacing.
Yes. The authoritative product specification identifies it as including a drain.
No. The authoritative pan type is non anti-splash.
